Chapter 1
Programming and Parameters
Chapter 3 provides a complete listing and description of the PowerFlex
700 parameters. The parameters can be programmed (viewed/edited)
using an LCD HIM (Human Interface Module). As an alternative,
programming can also be performed using DriveExplorer™ or
DriveExecutive™ software and a personal computer. Refer to Appendix
B for a brief description of the LCD HIM.
To configure a drive to operate in a specific way, drive parameters may
have to be set. Three types of parameters exist:
ENUM Parameters
ENUM parameters allow a selection from 2 or more items. The LCD
HIM will display a text message for each item.
Bit Parameters
Bit parameters have individual bits associated with features or
conditions. If the bit is 0, the feature is off or the condition is false. If
the bit is 1, the feature is on or the condition is true.
Numeric Parameters
These parameters have a single numerical value (i.e. 0.1 Volts).
The example on the following page shows how each parameter type is
presented in this manual.
For information on . . . See page . . .
About Parameters
1-1
How Parameters are Organized 1-3
Monitor File 1-12
Motor Control File 1-14
Speed Command File 1-21
Dynamic Control File 1-31
Utility File 1-38
Communication File 1-50
Inputs & Outputs File 1-54
Applications File 1-60
Parameter Cross Reference – by Name 1-62
Parameter Cross Reference – by Number 1-65
About Parameters
20B-UM001.book Page 1 Thursday, June 20, 2013 1:55 PM
