a
Drive
Code Type
20B PowerFlex 700
20B D 2P1 A 3 A Y N A E C 0 NN AD
abcdefghijklmn
b
Voltage Rating
Code Voltage Ph. Prechg. Frames
B 240V AC 3 - 0…6
C 400V AC 3 - 0…6
D 480V AC 3 - 0…6
E 600V AC 3 - 0…6
F 690V AC 3 - 5…6
H 540V DC - N 5…6
J 650V DC - N 5…6
N 325V DC - Y 5…6
P 540V DC - Y 5…6
R 650V DC - Y 5…6
T 810V DC - Y 5…6
W 932V DC - Y 5…6
c
ND Output Rating
Example
Code Amps kW (Hp)
2P2 2.2 0.37 (0.5)
022 22 5.5 (7.5)
e
HIM
Code Operator Interface
0 Blank Cover
3 LCD Display, Full Numeric Keypad
J ♦
Remote (Panel Mount), IP66, NEMA/UL
Type 12 Full Numeric LCD HIM
K ♦
Remote (Panel Mount), IP66, NEMA/UL
Type 12 Prog. Only LCD HIM
♦ Available with Frames 5…6 Stand-Alone IP54
drives (Enclosure Code "G").
l
Feedback
Code Type
0None
1 Encoder, 12V/5V
m
Future Use
n
Special Firmware (Frames 0…6 Only)
Code Type
AD ♦
60 Hz Maximum
AE ♦
Cascading Fan/Pump Control
AX ♦
82 Hz Maximum
BA ♦
Pump Off (for pump jack)
♦ Must be used with Vector Control option C or
D (Position k). Positions m-n are only required
when custom firmware is supplied.
d
Enclosure
Code Enclosure
A IP20, NEMA/UL Type 1
F ♠
Open/Flange Mount
Front: IP00, NEMA/UL Type Open
Back/Heatsink: IP54, NEMA Type 12
G ♠
Stand-Alone/Wall Mount
IP54, NEMA/UL Type 12
♠ Only available for Frame 5 & Frame 6 drives,
400…690V.
k
Control & I/O
Code Control I/O Volts
A Standard 24V DC/AC
B Standard 115V AC
C
Vector
Δ
24V DC
D
Vector
Δ
115V AC
N Standard None
Δ Vector Control Option utilizes DPI Only.
f
Documentation
Code Type
A Manual
N No Manual
Q
No Shipping Package
(Internal Use Only)
h
Internal Braking Resistor
Code w/Resistor
Y
Ye s
NNo
Not available for Frame 3 drives or larger.
i
Emission
Code CE Filter
§ CM Choke
AYesYes
B #
Ye s N o
NNoNo
§ Note: 600V class drives below 77 Amps
(Frames 0-4) are declared to meet the Low
Voltage Directive. It is the responsibility of the
user to determine compliance to the EMC
directive.
# Only available for 208…240V Frame 0-3 drives.
j
Comm Slot
Code Network Type
C ControlNet (Coax)
D DeviceNet
E EtherNet/IP
NNone
g
Brake
Code w/Brake IGBT
‡
YYes
NNo
‡ Brake IGBT is standard on Frames 0-3,
optional on Frames 4-6.
