A-2 Supplemental Drive Information
Table A.B DC Input
Typical Programmable Controller Configurations
Important: If block transfers are programmed to continuously write
information to the drive, care must be taken to properly
format the block transfer. If attribute 10 is selected for the
block transfer, values will be written only to RAM and will
not be saved by the drive. This is the preferred attribute for
continuous transfers. If attribute 9 is selected, each program
scan will complete a write to the drives non-volatile
memory (EEprom). Since the EEprom has a fixed number
of allowed writes, continuous block transfers will quickly
damage the EEprom. Do Not assign attribute 9 to
continuous block transfers. Refer to the individual
communications adapter User Manual for details.
Frame
325V 540V 650V 810V 932V
ND Hp HD Hp ND kW HD kW ND Hp HD Hp ND Hp HD Hp ND kW HD kW
0 0.5 0.33 – – 0.5 0.33 1 0.75 – –
10.75––10.7521.5––
––––21.532––
––––3253––
––––537.55––
––––7.55107.5––
1 2 1.5 0.37 0.25 10 7.5 15 10 – –
3 2 0.75 0.55 15 10 – – – –
531.50.75––––––
7.552.21.5––––––
––42.2––––––
––5.54––––––
––7.55.5––––––
––117.5––––––
2 107.5151120152015– –
– – 18.5 15 25 20 25 20 – –
3 15 10 22 18.5 30 25 30 25 – –
20 15 30 22 40 30 40 30 – –
– – 37 30 50 40 50 40 – –
4 25 20 45 37 60 50 60 50 – –
3025––––––––
5 40 30 55 45 75 60 100 75 45 37.5
50 40 – – 100 75 – – 90 75
6 60 50 75 55 125 100 150 125 132 110
75 60 90 75 150 125 – – – –
100 75 110 90 – – – – – –
– – 132 110 200 150 – – – –
Communication Configurations
20B-UM001.book Page 2 Thursday, June 20, 2013 1:55 PM
