1-62 Programming and Parameters
Parameter Cross Reference – by Name
Parameter Name Number Group Page
Accel Mask 281 Masks & Owners 1-52
Accel Owner 293 Masks & Owners 1-53
Accel Time X 140, 141 Ramp Rates 1-31
Alarm Clear 261 Alarms 1-48
Alarm Config 1 259 Alarms 1-48
Alarm X @ Fault 229, 230 Diagnostics 1-45
Alarm X Code 262-269 Alarms 1-48
Analog In X Hi 322, 325 Analog Inputs 1-55
Analog In X Lo 323, 326 Analog Inputs 1-55
Analog In X Loss 324, 327 Analog Inputs 1-55
Analog In1 Value 16 Metering 1-13
Analog In2 Value 17 Metering 1-13
Analog OutX Hi 343, 346 Analog Outputs 1-56
Analog OutX Lo 344, 347 Analog Outputs 1-56
Analog OutX Sel 342, 345 Analog Outputs 1-56
Anlg In Config 320 Analog Inputs 1-54
Anlg In Sqr Root 321 Analog Inputs 1-54
Anlg Out Absolut 341 Analog Outputs 1-55
Anlg Out Config 340 Analog Outputs 1-55
Anlg OutX Scale 354, 355 Analog Outputs 1-57
Anlg OutX Setpt 377, 378 Analog Outputs 1-57
Auto Rstrt Delay 175 Restart Modes 1-35
Auto Rstrt Tries 174 Restart Modes 1-35
Autotune 61 Torq Attributes 1-17
Autotune Torque 66 Torq Attributes 1-18
Break Frequency 72 Volts per Hertz 1-20
Break Voltage 71 Volts per Hertz 1-20
Brk Release Time 604 Torq Proving 1-61
Brk Set Time 607 Torq Proving 1-61
Brk Alarm Travel 610 Torq Proving 1-61
BrkSlip Count 609 Torq Proving 1-61
Bus Reg Kd 165 Stop/Brake Modes 1-34
Bus Reg Ki 160 Stop/Brake Modes 1-33
Bus Reg Kp 164 Stop/Brake Modes 1-34
Bus Reg Mode X 161, 162 Stop/Brake Modes 1-33
Commanded Freq 2 Metering 1-12
Commanded Speed 2 Metering 1-12
Commanded Torque 24 Metering 1-13
Compensation 56 Torq Attributes 1-16
Control Status 440 Torq Attributes 1-19
Control SW Ver 29 Drive Data 1-14
Current Lmt Gain 149 Load Limits 1-31
Current Lmt Sel 147 Load Limits 1-31
Current Lmt Val 148 Load Limits 1-31
Current Rate Limit 154 Load Limits 1-32
Data In XX 300-307 Datalinks 1-53
Data Out XX 310-317 Datalinks 1-54
DB Resistor Type 163 Stop/Brake Modes 1-34
DB While Stopped 145 Stop/Brake Modes 1-32
DC Brake Level 158 Stop/Brake Modes 1-33
DC Brake Time 159 Stop/Brake Modes 1-33
DC Brk Lvl Sel 157 Stop/Brake Modes 1-32
DC Bus Memory 13 Metering 1-13
DC Bus Voltage 12 Metering 1-13
Decel Mask 282 Masks & Owners 1-52
Decel Owner 294 Masks & Owners 1-53
Decel Time X 142, 143 Ramp Rates 1-31
Dig In Status 216 Diagnostics 1-44
Dig Out Setpt 379 Digital Outputs 1-59
Dig Out Status 217 Diagnostics 1-44
Dig OutX Level 381, 385,
389
Digital Outputs 1-59
Dig OutX OffTime 383, 387,
391
Digital Outputs 1-60
Dig OutX OnTime 382, 386,
390
Digital Outputs 1-60
Digital InX Sel 361-366 Digital Inputs 1-58
Digital OutX Sel 380, 384,
388
Digital Outputs 1-59
Direction Mask 279 Masks & Owners 1-52
Direction Mode 190 Direction Config 1-38
Direction Owner 291 Masks & Owners 1-53
DPI Baud Rate 270 Comm Control 1-50
DPI Data Rate 270 Comm Control 1-50
DPI Fdbk Select 299 Comm Control 1-51
DPI Port Sel 274 Comm Control 1-51
DPI Port Value 275 Comm Control 1-51
DPI Ref Select 298 Comm Control 1-51
Drive Alarm X 211, 212 Diagnostics 1-42
Drive Checksum 203 Drive Memory 1-41
Drive Logic Rslt 271 Comm Control 1-50
Drive OL Count 219 Diagnostics 1-44
Drive OL Mode 150 Load Limits 1-31
Drive Ramp Rslt 273 Comm Control 1-50
Drive Ref Rslt 272 Comm Control 1-50
Drive Status X 209, 210 Diagnostics 1-41
Drive Temp 218 Diagnostics 1-44
Droop RPM @ FLA 152 Load Limits 1-32
Elapsed kWh 014 Metering 1-13
Elapsed MWh 9 Metering 1-12
Elapsed Run Time 10 Metering 1-12
Enc Position Fdbk 414 Speed Feedback 1-20
Encoder PPR 413 Speed Feedback 1-20
Encoder Speed 415 Speed Feedback 1-20
Encoder Z Chan 423 Speed Feedback 1-21
Fault 1 Code 243 Faults 1-47
Fault 1 Time 244 Faults 1-47
Fault 2 Code 245 Faults 1-47
Fault 2 Time 246 Faults 1-47
Fault 3 Code 247 Faults 1-47
Fault 3 Time 248 Faults 1-47
Fault 4 Code 249 Faults 1-47
Fault 4 Time 250 Faults 1-47
Fault 5 Code 251 Faults 1-47
Fault 5 Time 252 Faults 1-47
Fault 6 Code 253 Faults 1-47
Fault 6 Time 254 Faults 1-47
Fault 7 Code 255 Faults 1-47
Fault 7 Time 256 Faults 1-47
Fault 8 Code 257 Faults 1-47
Fault 8 Time 258 Faults 1-47
