1-44 Programming and Parameters
UTILITY
Diagnostics
216 [Dig In Status]
Status of the digital inputs.
Read Only 361
thru
366
217 [Dig Out Status]
Status of the digital outputs.
Read Only 380
thru
384
218 [Drive Temp]
Present operating temperature of the
drive power section.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
219 [Drive OL Count]
Accumulated percentage of drive
overload. Continuously operating the
drive over 100% of its rating will increase
this value to 100% and cause a drive fault
or foldback depending on the setting of
[Drive OL Mode].
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
150
220 [Motor OL Count]
Accumulated percentage of motor
overload. Continuously operating the
motor over 100% of the motor overload
setting will increase this value to 100%
and cause a drive fault.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
047
048
224 [Fault Frequency]
Captures and displays the output speed
of the drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/+[Maximum Freq]
0.1 Hz
225
thru
230
[Fault Speed]
See description above.
Default:
Min/Max:
Units:
Read Only
0.0/+[Maximum Freq]
0.0/+[Maximum Speed]
0.1 Hz
0.1 RPM
079
225
thru
230
225 [Fault Amps]
Captures and displays motor amps at the
time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/[Rated Amps] × 2
0.1 Amps
224
thru
230
File Group No.
Parameter Name & Description
See page 1-2 for symbol descriptions
Values
Related
000000xxxxxxxxxx
10 01234567891112131415
1=Input Present
0=Input Not Present
x =Reserved
Bit #
Digital In1
Digital In2
Digital In3
Digital In4
Digital In5
Digital In6
00x 0xxxxxxxxxxxx
10 01234567891112131415
1=Output Energized
0=Output De-energized
x =Reserved
Bit # * Vector Control Option Only
Digital Out1
Digital Out2
Digital Out3 *
Standard
Vector
