Appendix C
Application Notes
Figure C.1 External Brake Resistor Circuitry
For information on . . See page . . For information on . . See page . .
External Brake Resistor
C-1 Process PI for Standard
Control
C-13
Lifting/Torque Proving C-2 Reverse Speed Limit C-16
Minimum Speed C-7 Skip Frequency C-17
Motor Control Technology C-8 Sleep Wake Mode C-19
Motor Overload C-10 Start At PowerUp C-21
Overspeed C-11 Stop Mode C-22
Power Loss Ride Through C-12 Voltage Tolerance C-24
External Brake Resistor
Power On
R (L1)
S (L2)
T (L3)
Power Source DB Resistor Thermostat
Power Off
M
M
(Input Contactor) M
Three-Phase
AC Input
20B-UM001.book Page 1 Thursday, June 20, 2013 1:55 PM
