Programming and Parameters 1-65
Parameter Cross Reference – by Number
Number Parameter Name Group Page
1 Output Freq Metering 1-12
2 Commanded Freq Metering 1-12
Commanded Speed Metering
3 Output Current Metering 1-12
4 Torque Current Metering 1-12
5 Flux Current Metering 1-12
6 Output Voltage Metering 1-12
7 Output Power Metering 1-12
8 Output Powr Fctr Metering 1-12
9 Elapsed MWh Metering 1-12
10 Elapsed Run Time Metering 1-12
11 MOP Frequency Metering 1-13
MOP Reference Metering
12 DC Bus Voltage Metering 1-13
014 Elapsed kWh Metering 1-13
13 DC Bus Memory Metering 1-13
16 Analog In1 Value Metering 1-13
17 Analog In2 Value Metering 1-13
22 Ramped Speed Metering 1-13
23 Speed Reference Metering 1-13
24 Commanded Torque Metering 1-13
25 Speed Feedback Metering 1-13
26 Rated kW Drive Data 1-14
27 Rated Volts Drive Data 1-14
28 Rated Amps Drive Data 1-14
29 Control SW Ver Drive Data 1-14
40 Motor Type Motor Data 1-14
41 Motor NP Volts Motor Data 1-14
42 Motor NP FLA Motor Data 1-14
43 Motor NP Hertz Motor Data 1-14
44 Motor NP RPM Motor Data 1-14
45 Motor NP Power Motor Data 1-15
46 Mtr NP Pwr Units Motor Data 1-15
47 Motor OL Hertz Motor Data 1-15
48 Motor OL Factor Motor Data 1-15
49 Motor Poles Motor Data 1-15
53 Motor Cntl Sel Torq Attributes 1-15
Torque Perf Mode Torq Attributes
54 Maximum Voltage Torq Attributes 1-15
55 Maximum Freq Torq Attributes 1-16
56 Compensation Torq Attributes 1-16
57 Flux Up Mode Torq Attributes 1-16
58 Flux Up Time Torq Attributes 1-16
59 SV Boost Filter Torq Attributes 1-16
61 Autotune Torq Attributes 1-17
62 IR Voltage Drop Torq Attributes 1-17
63 Flux Current Ref Torq Attributes 1-17
64 Ixo Voltage Drop Torq Attributes 1-17
66 Autotune Torque Torq Attributes 1-18
67 Inertia Autotune Torq Attributes 1-18
69 Start/Acc Boost Volts per Hertz 1-19
70 Run Boost Volts per Hertz 1-19
71 Break Voltage Volts per Hertz 1-20
72 Break Frequency Volts per Hertz 1-20
79 Speed Units Spd Mode & Limits 1-21
80 Feedback Select Spd Mode & Limits 1-22
Speed Mode Spd Mode & Limits
81 Minimum Speed Spd Mode & Limits 1-22
82 Maximum Speed Spd Mode & Limits 1-22
83 Overspeed Limit Spd Mode & Limits 1-22
84-86 Skip Frequency X Spd Mode & Limits 1-23
87 Skip Freq Band Spd Mode & Limits 1-23
88 Speed/Torque Mod Spd Mode & Limits 1-23
90, 93 Speed Ref X Sel Speed Reference 1-24
91, 94 Speed Ref X Hi Speed Reference 1-24
92, 95 Speed Ref X Lo Speed Reference 1-24
96 TB Man Ref Sel Speed Reference 1-25
97 TB Man Ref Hi Speed Reference 1-25
98 TB Man Ref Lo Speed Reference 1-25
99 Pulse Input Ref Speed Reference 1-25
100 Jog Speed Discrete Speeds 1-25
Jog Speed 1 Discrete Speeds
101-107 Preset Speed X Discrete Speeds 1-25
108 Jog Speed 2 Discrete Speeds 1-25
116 Trim % Setpoint Speed Trim 1-26
117 Trim In Select Speed Trim 1-26
118 Trim Out Select Speed Trim 1-26
119 Trim Hi Speed Trim 1-26
120 Trim Lo Speed Trim 1-26
121 Slip RPM @ FLA Slip Comp 1-26
122 Slip Comp Gain Slip Comp 1-26
123 Slip RPM Meter Slip Comp 1-26
124 PI Configuration Process PI 1-27
125 PI Control Process PI 1-27
126 PI Reference Sel Process PI 1-27
127 PI Setpoint Process PI 1-27
128 PI Feedback Sel Process PI 1-28
129 PI Integral Time Process PI 1-28
130 PI Prop Gain Process PI 1-28
131 PI Lower Limit Process PI 1-28
132 PI Upper Limit Process PI 1-28
133 PI Preload Process PI 1-28
134 PI Status Process PI 1-28
135 PI Ref Meter Process PI 1-28
136 PI Fdback Meter Process PI 1-28
137 PI Error Meter Process PI 1-29
138 PI Output Meter Process PI 1-29
139 PI BW Filter Process PI 1-29
140, 141 Accel Time X Ramp Rates 1-31
142, 143 Decel Time X Ramp Rates 1-31
145 DB While Stopped Stop/Brake Modes 1-32
146 S Curve % Ramp Rates 1-31
147 Current Lmt Sel Load Limits 1-31
148 Current Lmt Val Load Limits 1-31
149 Current Lmt Gain Load Limits 1-31
150 Drive OL Mode Load Limits 1-31
151 PWM Frequency Load Limits 1-31
152 Droop RPM @ FLA Load Limits 1-32
153 Regen Power Limit Load Limits 1-32
154 Current Rate Limit Load Limits 1-32
Number Parameter Name Group Page
