1-66 Programming and Parameters
155, 156 Stop Mode X Stop/Brake Modes 1-32
Stop/BRK Mode X Stop/Brake Modes
157 DC Brk Lvl Sel Stop/Brake Modes 1-32
158 DC Brake Level Stop/Brake Modes 1-33
159 DC Brake Time Stop/Brake Modes 1-33
160 Bus Reg Ki Stop/Brake Modes 1-33
161, 162 Bus Reg Mode X Stop/Brake Modes 1-33
163 DB Resistor Type Stop/Brake Modes 1-34
164 Bus Reg Kp Stop/Brake Modes 1-34
165 Bus Reg Kd Stop/Brake Modes 1-34
166 Flux Braking Stop/Brake Modes 1-34
167 Powerup Delay Restart Modes 1-34
168 Start At PowerUp Restart Modes 1-34
169 Flying Start En Restart Modes 1-35
170 Flying StartGain Restart Modes 1-35
174 Auto Rstrt Tries Restart Modes 1-35
175 Auto Rstrt Delay Restart Modes 1-35
177 Gnd Warn Level Power Loss 1-37
178 Sleep-Wake Mode Restart Modes 1-36
179 Sleep-Wake Ref Restart Modes 1-37
180 Wake Level Restart Modes 1-37
181 Wake Time Restart Modes 1-37
182 Sleep Level Restart Modes 1-37
183 Sleep Time Restart Modes 1-37
184 Power Loss Mode Power Loss 1-37
185 Power Loss Time Power Loss 1-37
186 Power Loss Level Power Loss 1-38
187 Load Loss Level Power Loss 1-38
188 Load Loss Time Power Loss 1-38
189 Shear Pin Time Power Loss 1-38
190 Direction Mode Direction Config 1-38
192 Save HIM Ref HIM Ref Config 1-39
193 Man Ref Preload HIM Ref Config 1-39
194 Save MOP Ref MOP Config 1-39
195 MOP Rate MOP Config 1-39
196 Param Access Lvl Drive Memory 1-39
197 Reset To Defalts Drive Memory 1-40
198 Load Frm Usr Set Drive Memory 1-40
199 Save To User Set Drive Memory 1-40
200 Reset Meters Drive Memory 1-40
201 Language Drive Memory 1-40
202 Voltage Class Drive Memory 1-41
203 Drive Checksum Drive Memory 1-41
209, 210 Drive Status X Diagnostics 1-41
211, 212 Drive Alarm X Diagnostics 1-42
213 Speed Ref Source Diagnostics 1-43
214 Start Inhibits Diagnostics 1-43
215 Last Stop Source Diagnostics 1-43
216 Dig In Status Diagnostics 1-44
217 Dig Out Status Diagnostics 1-44
218 Drive Temp Diagnostics 1-44
219 Drive OL Count Diagnostics 1-44
220 Motor OL Count Diagnostics 1-44
224 Fault Frequency Diagnostics 1-44
Fault Speed Diagnostics
225 Fault Amps Diagnostics 1-44
226 Fault Bus Volts Diagnostics 1-45
227, 228 Status X @ Fault Diagnostics 1-45
229, 230 Alarm X @ Fault Diagnostics 1-45
Number Parameter Name Group Page
234, 236 Testpoint X Sel Diagnostics 1-46
235, 237 Testpoint X Data Diagnostics 1-46
238 Fault Config 1 Faults 1-46
240 Fault Clear Faults 1-46
241 Fault Clear Mode Faults 1-47
242 Power Up Marker Faults 1-47
243 Fault 1 Code Faults 1-47
244 Fault 1 Time Faults 1-47
245 Fault 2 Code Faults 1-47
246 Fault 2 Time Faults 1-47
247 Fault 3 Code Faults 1-47
248 Fault 3 Time Faults 1-47
249 Fault 4 Code Faults 1-47
250 Fault 4 Time Faults 1-47
251 Fault 5 Code Faults 1-47
252 Fault 5 Time Faults 1-47
253 Fault 6 Code Faults 1-47
254 Fault 6 Time Faults 1-47
255 Fault 7 Code Faults 1-47
256 Fault 7 Time Faults 1-47
257 Fault 8 Code Faults 1-47
258 Fault 8 Time Faults 1-47
259 Alarm Config 1 Alarms 1-48
261 Alarm Clear Alarms 1-48
262-269 Alarm X Code Alarms 1-48
270 DPI Baud Rate Comm Control 1-50
DPI Data Rate Comm Control
271 Drive Logic Rslt Comm Control 1-50
272 Drive Ref Rslt Comm Control 1-50
273 Drive Ramp Rslt Comm Control 1-50
274 DPI Port Sel Comm Control 1-51
275 DPI Port Value Comm Control 1-51
276 Logic Mask Masks & Owners 1-51
277 Start Mask Masks & Owners 1-51
278 Jog Mask Masks & Owners 1-52
279 Direction Mask Masks & Owners 1-52
280 Reference Mask Masks & Owners 1-52
281 Accel Mask Masks & Owners 1-52
282 Decel Mask Masks & Owners 1-52
283 Fault Clr Mask Masks & Owners 1-52
284 MOP Mask Masks & Owners 1-52
285 Local Mask Masks & Owners 1-52
288 Stop Owner Masks & Owners 1-52
289 Start Owner Masks & Owners 1-52
290 Jog Owner Masks & Owners 1-52
291 Direction Owner Masks & Owners 1-53
292 Reference Owner Masks & Owners 1-53
293 Accel Owner Masks & Owners 1-53
294 Decel Owner Masks & Owners 1-53
295 Fault Clr Owner Masks & Owners 1-53
296 MOP Owner Masks & Owners 1-53
297 Local Owner Masks & Owners 1-53
298 DPI Ref Select Comm Control 1-51
299 DPI Fdbk Select Comm Control 1-51
300-307 Data In XX Datalinks 1-53
310-317 Data Out XX Datalinks 1-54
320 Anlg In Config Analog Inputs 1-54
321 Anlg In Sqr Root Analog Inputs 1-54
322, 325 Analog In X Hi Analog Inputs 1-55
Number Parameter Name Group Page
