1-52 Programming and Parameters
COMMUNICATIONS
Masks & Owners
278 [Jog Mask]
Controls which adapters can issue jog
commands.
See [Logic Mask]
. 288
thru
297
279 [Direction Mask]
Controls which adapters can issue
forward/reverse direction commands.
See [Logic Mask]
. 288
thru
297
280 [Reference Mask]
Controls which adapters can select an
alternate reference; [Speed Ref A, B Sel]
or [Preset Speed 1-7].
See [Logic Mask]
. 288
thru
297
281 [Accel Mask]
Controls which adapters can select
[Accel Time 1, 2].
See [Logic Mask]
. 288
thru
297
282 [Decel Mask]
Controls which adapters can select
[Decel Time 1, 2].
See [Logic Mask]
. 288
thru
297
283 [Fault Clr Mask]
Controls which adapters can clear a fault.
See [Logic Mask]
. 288
thru
297
284 [MOP Mask]
Controls which adapters can issue MOP
commands to the drive.
See [Logic Mask]
. 288
thru
297
285 [Local Mask]
Controls which adapters are allowed to
take exclusive control of drive logic
commands (except stop). Exclusive
“local” control can only be taken while the
drive is stopped.
See [Logic Mask]
. 288
thru
297
288 [Stop Owner]
Adapters that are presently issuing a valid stop
command.
Read Only 276
thru
285
289 [Start Owner]
Adapters that are presently issuing a
valid start command.
See [Stop Owner]
. 276
thru
285
290 [Jog Owner]
Adapters that are presently issuing a
valid jog command.
See [Stop Owner]
. 276
thru
285
File
Group
No.
Parameter Name & Description
See page 1-2 for symbol descriptions
Values
Related
000100xxxxxxxxxx
10 01234567891112131415
1=Issuing Command
0=No Command
x =Reserved
Bit #
Digital In
DPI Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
20B-UM001.book Page 52 Thursday, June 20, 2013 1:55 PM
