Programming and Parameters 1-43
UTILITY
Diagnostics
213 [Speed Ref Source]
Displays the source of the speed
reference to the drive.
(1)
Vector firmware 3.001 and later.
Default:
Options: 0
1
2
3-6
7
8
9
10
11-17
18
19
20
21
22
23
24
25
26
27
28
29
Read Only
“PI Output”
“Analog In 1”
“Analog In 2”
“Reserved”
“Pulse In”
“Encoder”
“MOP Level”
“Jog Speed 1”
“Preset Spd1-7”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“DPI Port 4”
“DPI Port 5”
“Reserved”
“Auto Tune”
“Jog Speed 2”
“Scale Block 1”
(1)
“Scale Block 2”
(1)
“Scale Block 3”
(1)
“Scale Block 4”
(1)
090
093
096
101
214 [Start Inhibits]
Displays the inputs currently preventing the drive
from starting.
Read Only
215 [Last Stop Source]
Displays the source that initiated the
most recent stop sequence. It will be
cleared (set to 0) during the next start
sequence.
Default:
Options: 0
1-5
6
7
8
9
10
11
12
13
Read Only
“Pwr Removed”
“DPI Port 1-5”
“Reserved”
“Digital In”
“Fault”
“Not Enabled”
“Sleep”
“Jog”
“Autotune”
“Precharge”
361
362
363
364
365
366
File
Group
No.
Parameter Name & Description
See page 1-2 for symbol descriptions
Values
Related
0000100x100000xx
10 01234567891112131415
1=Inhibit True
0=Inhibit False
x =Reserved
Bit #
Fault
Type 2 Alarm
Enable
DC Bus Pchrg
Stop Assertd
Params Reset
Startup Actv
Digital In
DPI Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
20B-UM001.book Page 43 Thursday, June 20, 2013 1:55 PM
