1-64 Programming and Parameters
Save HIM Ref 192 HIM Ref Config 1-39
Save MOP Ref 194 MOP Config 1-39
Save To User Set 199 Drive Memory 1-40
ScaleX In Hi 477-495 Scaled Blocks 1-48
ScaleX In Lo 478-496 Scaled Blocks 1-49
ScaleX In Value 476-494 Scaled Blocks 1-48
ScaleX Out Hi 479-497 Scaled Blocks 1-49
ScaleX Out Lo 480-498 Scaled Blocks 1-49
ScaleX Out Value 481-499 Scaled Blocks 1-49
Shear Pin Time 189 Power Loss 1-38
Skip Freq Band 87 Spd Mode & Limits 1-23
Skip Frequency X 84-86 Spd Mode & Limits 1-23
Sleep Level 182 Restart Modes 1-37
Sleep Time 183 Restart Modes 1-37
Sleep-Wake Mode 178 Restart Modes 1-36
Sleep-Wake Ref 179 Restart Modes 1-37
Slip Comp Gain 122 Slip Comp 1-26
Slip RPM @ FLA 121 Slip Comp 1-26
Slip RPM Meter 123 Slip Comp 1-26
Speed Desired BW 449 Speed Regulator 1-30
SpdBand Integrat 603 Torq Proving 1-61
Spd Dev Band 602 Torq Proving 1-61
Speed Feedback 25 Metering 1-13
Speed Loop Meter 451 Speed Regulator 1-30
Speed Mode 80 Spd Mode & Limits 1-22
Speed Ref Source 213 Diagnostics 1-43
Speed Ref X Hi 91, 94 Speed Reference 1-24
Speed Ref X Lo 92, 95 Speed Reference 1-24
Speed Ref X Sel 90, 93 Speed Reference 1-24
Speed Reference 23 Metering 1-13
Speed Units 79 Spd Mode & Limits 1-21
Speed/Torque Mod 88 Spd Mode & Limits 1-23
Start At PowerUp 168 Restart Modes 1-34
Start Inhibits 214 Diagnostics 1-43
Start Mask 277 Masks & Owners 1-51
Start Owner 289 Masks & Owners 1-52
Start/Acc Boost 69 Volts per Hertz 1-19
Status X @ Fault 227, 228 Diagnostics 1-45
Stop Mode X 155, 156 Stop/Brake Modes 1-32
Stop Owner 288 Masks & Owners 1-52
Stop/BRK Mode X 155, 156 Stop/Brake Modes 1-32
SV Boost Filter 59 Torq Attributes 1-16
TB Man Ref Hi 97 Speed Reference 1-25
TB Man Ref Lo 98 Speed Reference 1-25
TB Man Ref Sel 96 Speed Reference 1-25
Testpoint X Data 235, 237 Diagnostics 1-46
Testpoint X Sel 234, 236 Diagnostics 1-46
TorqLim SlewRate 608 Torq Proving 1-61
TorqProve Cnfg 600 Torq Proving 1-60
TorqProve Setup 601 Torq Proving 1-60
Torq Ref A Div 430 Torq Attributes 1-18
Torque Current 4 Metering 1-12
Torque Perf Mode 53 Torq Attributes 1-15
Torque Ref B Mult 434 Torq Attributes 1-18
Torque Ref X Hi 428, 432 Torq Attributes 1-18
Torque Ref X Lo 429, 433 Torq Attributes 1-18
Torque Ref X Sel 427, 431 Torq Attributes 1-18
Torque Setpoint 435 Torq Attributes 1-19
Torque Setpoint2 438 Torq Attributes 1-19
Parameter Name Number Group Page
Total Inertia 450 Speed Regulator 1-30
Trim % Setpoint 116 Speed Trim 1-26
Trim Hi 119 Speed Trim 1-26
Trim In Select 117 Speed Trim 1-26
Trim Lo 120 Speed Trim 1-26
Trim Out Select 118 Speed Trim 1-26
Voltage Class 202 Drive Memory 1-41
Wake Level 180 Restart Modes 1-37
Wake Time 181 Restart Modes 1-37
ZeroSpdFloatTime 605 Torq Proving 1-61
Parameter Name Number Group Page
