Programming and Parameters 1-63
Fault Amps 225 Diagnostics 1-44
Fault Bus Volts 226 Diagnostics 1-45
Fault Clear 240 Faults 1-46
Fault Clear Mode 241 Faults 1-47
Fault Clr Mask 283 Masks & Owners 1-52
Fault Clr Owner 295 Masks & Owners 1-53
Fault Config 1 238 Faults 1-46
Fault Frequency 224 Diagnostics 1-44
Fault Speed 224 Diagnostics 1-44
Fdbk Filter Sel 416 Speed Feedback 1-20
Feedback Select 80 Spd Mode & Limits 1-22
Float Tolerance 606 Torq Proving 1-61
Flux Braking 166 Stop/Brake Modes 1-34
Flux Current 5 Metering 1-12
Flux Current Ref 63 Torq Attributes 1-17
Flux Up Mode 57 Torq Attributes 1-16
Flux Up Time 58 Torq Attributes 1-16
Flying Start En 169 Restart Modes 1-35
Flying StartGain 170 Restart Modes 1-35
Gnd Warn Level 177 Power Loss 1-37
Inertia Autotune 67 Torq Attributes 1-18
IR Voltage Drop 62 Torq Attributes 1-17
Ixo Voltage Drop 64 Torq Attributes 1-17
Jog Mask 278 Masks & Owners 1-52
Jog Owner 290 Masks & Owners 1-52
Jog Speed 100 Discrete Speeds 1-25
Jog Speed 1 100 Discrete Speeds 1-25
Jog Speed 2 108 Discrete Speeds 1-25
Kf Speed Loop 447 Speed Regulator 1-30
Ki Speed Loop 445 Speed Regulator 1-29
Kp Speed Loop 446 Speed Regulator 1-30
Language 201 Drive Memory 1-40
Last Stop Source 215 Diagnostics 1-43
Load Frm Usr Set 198 Drive Memory 1-40
Load Loss Level 187 Power Loss 1-38
Load Loss Time 188 Power Loss 1-38
Local Mask 285 Masks & Owners 1-52
Local Owner 297 Masks & Owners 1-53
Logic Mask 276 Masks & Owners 1-51
Man Ref Preload 193 HIM Ref Config 1-39
Marker Pulse 421 Speed Feedback 1-21
Maximum Freq 55 Torq Attributes 1-16
Maximum Speed 82 Spd Mode & Limits 1-22
Maximum Voltage 54 Torq Attributes 1-15
MicroPos Scale% 611 Torq Proving 1-61
Minimum Speed 81 Spd Mode & Limits 1-22
MOP Frequency 11 Metering 1-13
MOP Mask 284 Masks & Owners 1-52
MOP Owner 296 Masks & Owners 1-53
MOP Rate 195 MOP Config 1-39
MOP Reference 11 Metering 1-13
Motor Cntl Sel 53 Torq Attributes 1-15
Motor Fdbk Type 412 Speed Feedback 1-20
Motor NP FLA 42 Motor Data 1-14
Motor NP Hertz 43 Motor Data 1-14
Motor NP Power 45 Motor Data 1-15
Motor NP RPM 44 Motor Data 1-14
Motor NP Volts 41 Motor Data 1-14
Motor OL Count 220 Diagnostics 1-44
Parameter Name Number Group Page
Motor OL Factor 48 Motor Data 1-15
Motor OL Hertz 47 Motor Data 1-15
Motor Poles 49 Motor Data 1-15
Motor Type 40 Motor Data 1-14
Mtr NP Pwr Units 46 Motor Data 1-15
Mtr Tor Cur Ref 441 Torq Attributes 1-19
Neg Torque Limit 437 Torq Attributes 1-19
Notch Filter Freq 419 Speed Feedback 1-20
Notch Filter K 420 Speed Feedback 1-21
Output Current 3 Metering 1-12
Output Freq 1 Metering 1-12
Output Power 7 Metering 1-12
Output Powr Fctr 8 Metering 1-12
Output Voltage 6 Metering 1-12
Overspeed Limit 83 Spd Mode & Limits 1-22
Param Access Lvl 196 Drive Memory 1-39
PI BW Filter 139 Process PI 1-29
PI Configuration 124 Process PI 1-27
PI Control 125 Process PI 1-27
PI Deriv Time 459 Process PI 1-29
PI Error Meter 137 Process PI 1-29
PI Fdback Meter 136 Process PI 1-28
PI Feedback Hi 462 Process PI 1-29
PI Feedback Lo 463 Process PI 1-29
PI Feedback Sel 128 Process PI 1-28
PI Integral Time 129 Process PI 1-28
PI Lower Limit 131 Process PI 1-28
PI Output Meter 138 Process PI 1-29
PI Preload 133 Process PI 1-28
PI Prop Gain 130 Process PI 1-28
PI Ref Meter 135 Process PI 1-28
PI Reference Hi 460 Process PI 1-29
PI Reference Lo 461 Process PI 1-29
PI Reference Sel 126 Process PI 1-27
PI Setpoint 127 Process PI 1-27
PI Status 134 Process PI 1-28
PI Upper Limit 132 Process PI 1-28
Pos Torque Limit 436 Torq Attributes 1-19
Power Loss Level 186 Power Loss 1-38
Power Loss Mode 184 Power Loss 1-37
Power Loss Time 185 Power Loss 1-37
Power Up Marker 242 Faults 1-47
Powerup Delay 167 Restart Modes 1-34
Preset Speed X 101-107 Discrete Speeds 1-25
Pulse In Scale 422 Speed Feedback 1-21
Pulse Input Ref 99 Speed Reference 1-25
PWM Frequency 151 Load Limits 1-31
Ramped Speed 22 Metering 1-13
Rated Amps 28 Drive Data 1-14
Rated kW 26 Drive Data 1-14
Rated Volts 27 Drive Data 1-14
Reference Mask 280 Masks & Owners 1-52
Reference Owner 292 Masks & Owners 1-53
Regen Power Limit 153 Load Limits 1-32
Reset Meters 200 Drive Memory 1-40
Reset To Defalts 197 Drive Memory 1-40
Rev Speed Limit 454 Speed Regulator 1-23
Run Boost 70 Volts per Hertz 1-19
S Curve % 146 Ramp Rates 1-31
Parameter Name Number Group Page
