Programming and Parameters 1-49
UTILITY
Scaled Blocks
478
484
490
496
[Scale1 In Lo]
[Scale2 In Lo]
[Scale3 In Lo]
[Scale4 In Lo]
Scales the lower value of [ScaleX In
Value].
(1)
Blocks 3 & 4 only.
Default:
Min/Max:
Units:
0.0
–/+32000.0
–/+32767.0 (v2.xxx)
–/+32767.000
(1)
0.1
0.001
479
485
491
497
[Scale1 Out Hi]
[Scale2 Out Hi]
[Scale3 Out Hi]
[Scale4 Out Hi]
Scales the upper value of [ScaleX Out
Value].
(1)
Blocks 3 & 4 only.
Default:
Min/Max:
Units:
0.0
–/+32000.0
–/+32767.0 (v2.xxx)
–/+32767.000
(1)
0.1
0.001
480
486
492
498
[Scale1 Out Lo]
[Scale2 Out Lo]
[Scale3 Out Lo]
[Scale4 Out Lo]
Scales the lower value of [ScaleX Out
Value].
(1)
Blocks 3 & 4 only.
Default:
Min/Max:
Units:
0.0
–/+32000.0
–/+32767.0 (v2.xxx)
–/+32767.000
(1)
0.1
0.001
481
487
493
499
[Scale1 Out Value]
[Scale2 Out Value]
[Scale3 Out Value]
[Scale4 Out Value]
Value of the signal being sent out of the
Universal Scale block. Typically this value
is used as the source of information and
will be linked to another parameter.
(1)
Blocks 3 & 4 only.
Default:
Min/Max:
Units:
Read Only
–/+32000.0
–/+32767.0 (v2.xxx)
–/+32767.000
(1)
0.1
0.001
File
Group
No.
Parameter Name & Description
See page 1-2 for symbol descriptions
Values
Related
20B-UM001.book Page 49 Thursday, June 20, 2013 1:55 PM
