Publication 2098-IN005C-EN-P — March 2008
Interconnect Diagrams 121
In this figure, the 2098-DSD-HV150x-xx or 2098-DSD-HV220x-xx
Ultra3000 drive is wired to a Bonitron shunt module.
External Passive Shunt (Bonitron shunt) Diagram
TB2
1
2
3
GRN
115VAC
Fan
RES
TEMP
Alarm
1
2
3
4
5
6
7
External Passive Shunt
Resistor Connections
M3575R-Hxxxx
Bonitron
Shunt Module *
2098-DSD-HV150x-xx
or
2098-DSD-HV220x-xx
Ultra3000
Digital Servo Drives
Bonded Cabinet
Ground Bus*
115V ac
Fan Power*
STOP*
START*
CR1*
CR1*
CR1*
M1*
Refer to Attention statement (Notes 10, 11)
120V ac
50/60 Hz
* Indicates User-supplied Component
Shunt Wiring Methods:
Twisted pair in conduit (1st choice).
Shielded twisted pair (2nd choice).
Twisted pair, 2 twists per foot min. (3rd choice).
Maximum Length: 3.05 m (10 ft).
To Next Page
