Rockwell Automation Allen-Bradley Ultra3000

Publication 2098-IN005C-EN-P — March 2008
Interconnect Diagrams 131
Controlling a Brake
Example
The relay output of the Ultra3000 drive (pins CN1-43 and CN1-44) is
suitable for directly controlling a motor brake, subject to the relay
voltage limit of 30V dc, and the relay current limit of 1 A dc. For brake
requirements outside of these limits, an external relay must be used. If
a transistor output is used, a control relay is also required.
Coil Currents Rated at < 1.0 A
Coil Currents Rated at >1.0 A and ≤
1.3 A
Coil Currents Rated at >1.3 A and ≤
3.0 A
Compatible Brake Motors
(1)
Coil Current Compatible Brake Motors/Actuators Coil Current
MPL-x1510, MPL-x1520, MPL-x1530 0.43…0.53 A MPG-x004 0.30…0.36 A
MPL-x210, MPL-x220, MPL-x230 0.46…0.56 A MPG-x010
0.41…0.49 A
MPL/MPF-x310, MPL/MPF-x320, MPL/MPF-x330
0.45…0.55 A
MPG-x025
MPS-x330 MPG-x050 0.45…0.55 A
MPL-x420, MPL-x430, MPL-x4520, MPL-x4530,
MPL-x4540, MPL-B4560
0.576…0.704 A
MPG-x110 0.90…1.10 A
MPF-x430, MPF-x4530, MPF-x4540 TLY-A110-H, TLY-A120-H, and TLY-A130-H 0.18…0.22 A
MPS-x4540 TLY-A220-H and TLY-A230-H 0.333…0.407 A
1326AB-B4xxx 0.88 A TLY-A2530-H and TLY-A2540-H 0.351…0.429 A
F-4030, F-4050, and F-4075 0.69 A TLY-A410-H 0.648…0.792 A
(1)
Use of the variable x indicates this specification applies to 230V and 460V motors.
Compatible Brake Motors Coil Current Compatible Brake Motors Coil Current
MPL-x520, MPL-x540, MPL-x560, MPL-x580
(1)
1.05…1.28 A
F-6100, F-6200, and F-6300 1.30 A
MPF-x540
(1)
1326AB-B5xxx and 1326AB-B7xxx 1.20 A
MPS-B560
(1)
Use of the variable x indicates this specification applies to 230V and 460V motors.
Compatible Brake Motors Coil Current
MPL-B640, MPL-B660, and MPL-B680
1.91…2.19 AMPL-B860 and MPL-B880
MPL-B960 and MPL-B980
