Rockwell Automation Allen-Bradley Ultra3000 Integration Manual

Publication 2098-IN005C-EN-P — March 2008
Commissioning Your Ultra3000 Drive 71
5. If using Overtravel inputs, verify that 12…24V dc is tied to CN1-37
and CN1-38.
Fiber-optic Ring Connections
Ultra3000-SE Drive Node Addressing
IMPORTANT
Without CN1-37 and CN1-38 inputs applied, the drive/
system will fault.
0
8
4
C
6
7
5
3
2
1
9
A
B
E
D
F
TX
RX
OK
CP
Ultra3000-SE
Drive
Receive
Transmit
SERCOS Fiber-optic Ring
Ultra3000-SE
Drive
Receive
Transmit
Receive
Transmit
Logix Platform
(SoftLogix 1784-PM16SE
SERCOS PCI Card is shown)
1756-M08SE SERCOS interface Module
Ultra3000-SE Drive
Number 1
MSD = 1
LSD = 0
Node Address = 10
Ultra3000-SE Drive
Number 2
MSD = 1
LSD = 1
Node Address = 11
SERCOS Ring
SERCOS Ring
SERCOS Ring
Logix Platform
(ControlLogix
platform is shown)
