Rockwell Automation PowerFlex 755TM User Manual

100 Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022
Appendix B Power Component Accessories
• If any 20GxD/E… common bus inverter or 20JxF regenerative bus supply is frame 8…10 with -P46 option code in its respective catalog
number
Figure 16 - Frame 10 Bus Supply (layout is typical for other Frames 10...15)
Figure 17 - Frame 10 Common Bus Inverter (layout is typical for other Frames 10...15)
DC Bus
DC Bus
PE
