Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022 79
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
690V AC Rating Tables
This section contains 690V AC rating tables.
Table 18 - PowerFlex 750-Series Drives — Frames 6 and 7, 690V AC
Cat. No.
20F…/
20G…
(1)
(1) Drive input type (position 5 of catalog number) = 1 (AC input with precharge, includes DC terminals) or 4 (DC input
with precharge).
Frame
Size
AC Output
Rating
kW
AC Output Rating
Amp RMS DC Input Rating
Internal DC Bus
Capacitance (µF)ND HD ND HD Amps kW
F012 6
7.5 — 12 — 13.2 12.3
2600
— 5.5 — 9 9.9 9.2
F015 6
11 — 15 — 16.5 15.4
2600
—7.5—1213.212.3
F020 6
15 — 20 — 21.9 20.4
2600
— 11 — 15 16.5 15.4
F023 6
18.5 — 23 — 25.2 23.5
2600
— 15 — 20 21.9 20.4
F030 6
22 — 30 — 32.9 30.7
2600
— 18.5 — 23 25.2 23.5
F034 6
30 — 34 — 37.3 34.8
2600
— 22 — 30 32.9 30.7
F046 6
37 — 46 — 50.5 47.1
2600
— 30 — 34 37.5 34.8
F050 6
45 — 50 — 54.8 51.1
2600
—37—4650.547.1
F061 6
55 — 61 — 66.9 62.4
5200
— 45 — 50 54.8 51.1
F082 6
75 — 82 — 89.9 83.8
5200
— 55 — 61 66.9 62.4
F098 6
90 — 98 — 107.5 100.2
5200
— 75 — 82 89.9 83.8
F119 6
110 — 119 — 130.5 121.6
5200
— 90 — 98 107.5 100.2
F142 6
132 — 142 — 155.7 145.1
5200
— 110 — 119 130.5 121.6
F171 7
160 — 171 — 187.5 174.8
11700
— 132 — 142 155.7 145.1
F212 7
200 — 212 — 232.5 216.7
11700
—160—171187.5174.8
F263 7
250 — 263 — 288.4 268.8
11700
— 200 — 212 232.5 216.7
