80 Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 19 - PowerFlex 755TM Common Bus Inverters — Frames 8…12, 690V AC
Cat. No.
20G…
(1)
(1) Drive input type (position 5 of catalog number) = D (common bus with DC precharge) or E (common bus
without DC precharge).
Frame
Size
AC Output Rating
kW
AC Output Rating
Amp RMS DC Input Rating
Internal DC Bus
Capacitance (µF)ND HD ND HD Amps kW
F215 8
200 — 215 — 237 220.9
4650
—160—171188175.2
F265 8
250 — 265 — 292 272.1
4650
— 200 — 215 237 220.9
F330 8
315 — 330 — 364 339.2
4650
— 250 — 265 292 272.1
F370 8
355 — 370 — 408 380.3
4650
— 315 — 330 364 339.2
F415 8
400 — 415 — 457 425.9
7750
—355—370408380.3
F505 8
500 — 505 — 556 518.2
7750
—400—415457425.9
F565 9
560 — 565 — 623 580.6
9300
— 500 — 505 556 518.2
F650 9
630 — 650 — 716 667.3
9300
— 560 — 565 623 580.6
F735 9
710 — 735 — 810 754.9
15500
— 630 — 650 716 667.3
F820 9
800 — 820 — 904 842.5
15500
—710—735810754.9
F920 9
900 — 920 — 1014 945
15500
—800—820904842.5
F1K0 10
1000 — 1030 — 1135 1057.8
23250
— 900 — 920 1014 945
F1K1 10
1100 — 1150 — 1267 1180.8
23250
— 1000 — 1030 1135 1057.8
F1K4 10
1400 — 1419 — 1564 1457.6
23250
— 1100 — 1162 1280 1193
F1K8 11
1800 — 1865 — 2055 1915.3
31000
— 1500 — 1535 1692 1576.9
F2K3 12
2300 — 2318 — 2554 2380.3
38750
— 2000 — 2020 2226 2074.6
F2K7 13
2750 — 2778 — 3058 2850.1
46500
—200—228325142343
F3K6 14
3650 — 3687 — 4059 3783
62000
— 2920 — 3030 3336 3109.2
F4K5 15
4550 — 4596 — 5060 4715.9
77500
— 3640 — 3777 4159 3876.2
