Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
600V AC Rating Tables
This section contains 600V AC rating tables.
Table 14 - PowerFlex 750-Series Drives — Frames 3…7, 600V AC
Cat. No.
20F…/
20G…
(1)
Frame
Size
AC Output Rating
HP
AC Output Rating
Amp RMS DC Input Rating
Internal DC Bus Capacitance (µF)ND HD ND HD Amps kW
E1P7 3
1 — 1.7 — 1.9 1.5
1500
—0.5— 0.91 0.8
E2P7 3
2—2.7— 3 2.4
1500
—1 — 1.7 1.9 1.5
E3P9 3
3—3.9— 4.33.5
1500
— 2 — 2.7 3 2.4
E6P1 3
5 — 6.1 — 6.7 5.4
1500
—3 — 3.9 4.3 3.5
E9P0 3
7.5 — 9 — 9.9 8
1500
—5 — 6.1 6.7 5.4
E011 3
10 — 11 — 12 9.7
1500
—7.5— 9 9.9 8
E012 6
10 — 12 — 13.1 10.6
2600
—7.5— 9.1 10 8.1
E017 3
15 — 17 — 18.6 15.1
1500
—10— 11 12 9.7
E018 6
15 — 18 — 19.7 16
2600
— 10 — 12 13.1 10.6
E022 3
20 — 22 — 24.1 19.5
1500
— 15 — 17 18.6 15.1
E023 6
20 — 23 — 25.2 20.4
2600
— 15 — 18 19.7 16
E024 6
20 — 24 — 26.3 21.3
2600
—20— 22 24.119.5
E027 4
25 — 27 — 29.6 24
1800
—20— 22 24.119.5
E028 6
25 — 28 — 30.7 24.9
2600
— 20 — 23 25.2 20.4
E032 4
30 — 32 — 35 28.4
1800
— 25 — 27 29.6 24
E033 6
30 — 33 — 36.1 29.2
2600
—25— 28 30.724.9
E041 5
40 — 41 — 44.9 36.4
3600
— 30 — 32 35 28.4
E042 6
40 — 42 — 46 37.3
2600
— 30 — 33 36.1 29.2
E052 5
50 — 52 — 56.9 46.1
3600
— 40 — 41 44.9 36.4
E053 6
50 — 53 — 58 47
2600
—40— 42 46 37.3
