Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 13 - PowerFlex 755TM Non-regenerative Supplies – Single and Dual Density, 480V AC (650V DC Output)
Cat.No.
20JEH... Module Size
(1)
(1) Modules are available in single density and dual density. Modules can be paralleled to increase the rating. In this table ‘1X’ means
one single-density module, ‘2X’ means one dual-density module. See Paralleling PowerFlex 755TM Non-regenerative Modules on
page 41 for more information.
DC Output Rating
(1)
Internal Optional DC Bus Cap (uF)
(2)
(2) For paralleled modules, sum the corresponding 1X and 2X internal optional capacitance values to obtain the overall bus supply
internal/optional DC bus capacitance value.
kW Rating
Cont.
AmpsND HD
D740 1X
529 - 817
15,000
-441681
D1K3 2X
977 - 1507
30,000
- 812 1253
20-750-MN…
(3)
(3) Parallel configurations are built-up from separate enclosures and 20-750-MN… single-density 1X and dual-density 2X roll-in
modules. See the PowerFlex 755TM IP00 Open Type Kits Technical Data, publication 750-TD101.
1X/2X
1482 - 2288
Total internal uF values calculated based on
module size and quantity of parallel modules
-12361907
2X/2X
1959 - 3023
-16332520
1X/2X/2X
2435 - 3758
-21323290
2X/2X/2X
2912 - 4494
-24273746
1X/1X/ 2912 - 4494
2X/x2X - 2427 3746
2X/2X/ 3865 - 5964
2X/2X - 3221 4871
1X/1X/ 4818 - 7435
2X/2X/2X/2X - 4016 6197
2X/2X/2X/2X/2X/2X
(4)
(4) The ratings for the configurations in these rows can only be achieved by using customer-sourced bus bars.
5171 - 8905
-48107423
Cat.No.
20JEH…
Module
Size
(1)
(1) Modules are available in single density and dual density. Modules can be paralleled to increase the rating. In this table ‘1X’ means one single-density module, ‘2X’ means
one dual-density module. See Paralleling PowerFlex 755TM Non-regenerative Modules on page 41
for more information.
Maximum DC Bus Capacitance (uF)
(2) (3)
(2) For paralleled modules, sum the corresponding 1X and 2X maximum external capacitance values to obtain the overall bus supply system maximum external DC bus
capacitance value.
(3) Select the fastest precharge ramp time that supports the total connected DC bus capacitance. Perform calculations to determine the required DC bus capacitance and
the system total DC bus capacitance. See DC Bus Capacitance Calculation Method on page 87
.
Precharge
Ramp
0.2 s
Precharge
Ramp
1.3 s
Precharge
Ramp
2.0 s
Precharge
Ramp
5.0 s
Precharge
Ramp
10 s
Precharge
Ramp
20 s
Precharge
Ramp
30 s
Precharge
Ramp
60 s
D740 1X 81,700 408,500 817,000 2,042,500 4,085,000 8,170,000 12,255,000 24,510,000
D1K3 2X 150,700 753,500 1,507,000 3,767,500 7,535,000 15,070,000 22,605,000 45,210,000
