Rockwell Automation PowerFlex 755TM User Manual

108 Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022
Appendix C PowerFlex 755TL/TR AC Drive Electrical Ratings and DC Bus Capacitance
480V AC Input
Table 25 - PowerFlex 755TL/TR Frames 5…15 480V AC Input
Cat. No.
20G…
(1)
Frame
Size
AC Output Rating
Internal DC Bus
Capacitance (µF)
Max External
Capacitance (µF)
HP Rating
Continuous
AmpsND HD
D014 5
10 - 14
3000 3192
-7.511
D022 5
15 - 22
3000 3192
-1014
D027 5
20 - 27
3000 3192
-1522
D034 5
25 - 34
3000 3192
-2027
D040 5
30 - 40
3000 1692
-2534
D052 5
40 - 52
4500 1692
-3040
D065 5
50 - 65
4500 1692
-4052
D077 5
60 - 77
4500 1692
-5065
D096 5
75 - 96
4500 1692
-6077
D125 6
100 - 125
9200 880
-7596
D156 6
125 - 156
9200 880
-100125
D186 6
150 - 186
13800 2184
-125156
D248 6
200 - 248
13800 2184
-150186
D302 7
250 - 305
18000 59472
-200248
D361 7
300 - 361
18000 59472
-250302
D430 7
350
-
-430
18000 59472
300 361
D505 7
400 - 505
18000 59472
-350430
D617 7
500 - 600
18000 59472
-400500
D302 8
250 - 302
18000 47088
-200248
D361 8
300 - 361
18000 47088
-250302
D430 8
350 - 430
18000 47088
-300361
