PowerFlex 755TL/TR AC Drive Electrical Ratings and DC Bus Capacitance
The tables in this appendix provide PowerFlex® 755TL/755TR drive ratings (including AC output ratings) and internal drive DC bus capacitance.
400V AC Rating Table
Table 24 - PowerFlex 755TL/TR Frames 5…15 400V AC Input
Cat. No.
20G…
(1)
Frame
Size
AC Output Rating
Internal DC Bus
Capacitance (µF)
Max External
Capacitance (µF)
kW Rating
Continuous
AmpsND HD
C015 5
7.5 - 15.4
3000 3984
- 5.5 11.5
C022 5
11 - 22
3000 3984
-7.515.4
C030 5
15 - 30
3000 3984
-1122
C037 5
18.5 - 37
3000 3984
15 30
C043 5
22 - 43
3000 3984
-18.537
C060 5
30 - 60
4500 2484
-2243
C072 5
37 - 72
4500 2484
-3060
C085 5
45 - 85
4500 2484
-3772
C104 5
55 - 104
4500 2484
-4585
C140 6
75 - 140
9200 2248
-55104
C176 6
90 - 170
9200 2248
-75140
C205 6
110 - 205
13800 3696
-90170
C260 6
132 - 260
13800 3696
- 110 205
C302 7
160 - 302
18000 62784
-132260
C367 7
200 - 367
18000 62784
-160302
C460 7
250 - 460
18000 62784
-200367
