Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022 103
Appendix B Power Component Accessories
If Kinetix 5700 inverters are used with an external non-regenerative DC-bus power supply, the 2198-CAPMOD-2240 capacitor module is required
along with the 2198-CAPMODDCBUS-IO extension module to provide connections to the DC+ and DC- lug terminals. See the Kinetix 5700 Servo Drive
User Manual, publication 2198-UM002
, for more information.
Figure 18 - Kinetix 5700 Servo Drive System with PowerFlex 755TM Bus Supply (illustrative purpose only)
See the following Kinetix 5700 documentation for more information about common DC bus applications.
• Regenerative Bus Supply Installation Instructions, publication 2198-IN014
• Kinetix 5700 Servo Drives User Manual, publication 2198-UM002
• Drives in Common Bus Configurations with Kinetix 5700 Bus Supplies, publication MOTION-AT007A-EN-P
