Rockwell Automation PowerFlex 755TM User Manual

Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022 15
Chapter 1 DC Bus Wiring Guidelines
Figure 8 - Kinetix 5700 Dual-axis Servo Block Diagram
24V+
24V–
DC+
BR+
BR–
U
V
W
DC–
U
V
W
BR+
BR–
Ground Jumper
(1)
Control
Chassis
Motor Power
(MP) Connector - B
Chassis
Motor Power
(MP) Connector - A
24V Control Power
(CP) Connector
Motor Brake
(BC) Connector - A
Motor Brake
(BC) Connector - B
Control
(1) Ground jumper installed on 2198-Sxxx-ERS3 (series A) drives.
Ground jumper removed on 2198-Sxxx-ERS4 and 2198-Sxxx-ERS3 (Series B) drives.
