Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
C260 7
132 — 260 — 297.7 160.8
13800
— 110 — 205 234.7 126.7
C302 7
160 — 302 — 345.7 186.7
13800
— 132 — 260 297.7 160.7
C367 7
200 — 367 — 420.2 226.9
13800
— 160 — 302 345.7 186.7
C456 7
250 — 456 — 522 281.9
18400
— 200 — 367 420.2 226.9
C477 7
270 477 — 546 294.8
18400
200 — 367 420.2 226.9
(1) Drive input type (position 5 of catalog number) = 1 (AC input with precharge, includes DC terminals) or 4 (DC input with
precharge).
Table 4 - PowerFlex 750-Series Drives — Frames 1…7, 400V AC (Continued)
Cat. No.
20F…/
20G…
(1)
Frame
Size
AC Output Rating kW
AC Output Rating
Amp RMS DC Input Rating
Internal DC
Bus
Capacitance
(µF)
ND HD ND HD
Amps kW
