Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
Table 16 - PowerFlex 755TM Regenerative Bus Supplies — Frames 6…15, 600V AC (870V DC Output)
Cat. No.
20J…
(1)
Frame
Size
DC Output Rating
Internal DC Bus Capacitance (μF) Max External DC Bus Capacitance (μF)
kW
Continuous
AmpsND HD
E077 6
69 — 79
3100 5871
—5664
E099 6
89 — 102
3100 5871
—6979
E125 6
112 — 129
4650 8353
—89102
E144 6
129 — 148
4650 8353
— 112 129
E192 7
171 — 197
4650 31033
—129148
E242 7
217 — 249
4650 31033
—171197
E295 7
263 — 303
4650 31033
—217249
E355 7
317 — 365
4650 31033
—263303
E395 7
353 — 406
4650 31033
—317365
E242 8
217 - 249
4650 31033
-171197
E295 8
263 - 303
4650 31033
-217249
E355 8
317 - 365
4650 31033
-263303
E395 8
353 - 406
4650 31033
-317365
E435 8
389 - 447
7750 41440
-353406
E545 8
487 - 560
7750 41440
-403463
E595 9
518 - 596
9300 52994
- 487 560
E690 9
617 - 710
9300 52994
-532612
E760 9
680 - 782
15500 73002
-617710
E825 9
737 - 848
15500 73002
-680782
E980 9
877 - 1008
15500 73002
-737848
E1K1 10
935 - 1075
23250 105875
- 877 1008
E1K2 10
1091 - 1255
23250 105875
-9351075
