Rockwell Automation PowerFlex 755TM User Manual

Rockwell Automation Publication DRIVES-AT005D-EN-P - May 2022 91
Appendix A Electrical Ratings, Recommended Protective Devices, and DC Bus Capacitance
20G14NE012AN0NNNNN 1
PowerFlex 755 AC Drive, with Embedded EtherNet/IP, Air Cooled, DC Input with Precharge, Open Type, 12 A, 10 HP ND, 7.5 HP
HD, 600V AC, 3 PH, Frame 6, Filtered, CM Jumper Removed, None, Blank (No HIM)
HSJ20 2 600VAC 20 A Class J HS Fuse
1321-M180 1 Common Mode Choke, 180 A, Open Style
20G11NE022AA0NNNNN 1
PowerFlex 755 AC Drive, with Embedded EtherNet/IP, Air Cooled, AC Input with DC Terminals, Open Type, 22 A, 20 HP ND, 15 HP
HD, 600V AC, 3 PH, Frame 3, Filtered, CM Jumper Removed, DB Transistor, Blank (No HIM)
HSJ40 2 600VAC 40 A Class J HS Fuse
1321-M048 1 Common Mode Choke, 45 A, Open Style
20G11NE027AA0NNNNN 1
PowerFlex 755 AC Drive, with Embedded EtherNet/IP, Air Cooled, AC Input with DC Terminals, Open Type, 27 A, 25 HP ND, 20 HP
HD, 600V AC, 3 PH, Frame 4, Filtered, CM Jumper Removed, DB Transistor, Blank (No HIM)
HSJ50 2 600VAC 50 A Class J HS Fuse
1321-M180 1 Common Mode Choke, 180 A, Open Style
20G14NE042AA0NNNNN 1
PowerFlex 755 AC Drive, with Embedded EtherNet/IP, Air Cooled, DC Input with Precharge, Open Type, 42 A, 40 HP ND, 30 HP
HD, 600V AC, 3 PH, Frame 6, Filtered, CM Jumper Removed, DB Transistor, Blank (No HIM)
HSJ70 2 600VAC 70 A Class J HS Fuse
1321-M180 1 Common Mode Choke, 180 A, Open Style
20G14NE052AA0NNNNN 1
PowerFlex 755 AC Drive, with Embedded EtherNet/IP, Air Cooled, DC Input with Precharge, Open Type, 52 A, 50 HP ND, 40 HP
HD, 600V AC, 3 PH, Frame 5, Filtered, CM Jumper Removed, DB Transistor, Blank (No HIM)
HSJ90 2 600VAC 90 A Class J HS Fuse
1321-M180 1 Common Mode Choke, 180 A, Open Style
Sample Bill of Material (Continued)
Cat. No. Qty. Description
