Aug. 2006
20
15129623 TRANSISTOR 2SD-667C Q18 on Audio B. 1
DIODE
01897189 DIODE MA147-(TX) CHIP D8 on Main B. 6
D5,D10,D25,D26,D28 on Audio B.
J5019123 DIODE SCHOTTKY SK13 CHIP D2,D4,D6,D8 on Audio B. 4
A 02780401 CEA SCHOTTKY DIODE MA720-(TX) D1 on Main B. 2
D27 on Audio B.
# J5029125 LED DIODE SML-012UTT86A RED SMD D1,D3,D4,D5,D6,D8,D9, 62
D11,D12,D13,D14,D15,D16,
D17,D19,D20,D22,D23,D24,
D25,D27,D28,D29,D30,D31,
D32,D33 on Right Control B.
D1,D2,D3,D4,D5,D6,D7,D8,
D9,D10,D11,D12,D13,D14,
D15,D17,D18,D19,D20,D21,
D22,D24,D25,D26,D27,D28,
D29 on Left Control B.
D1,D2,D3,D5,D6,D7,D8 on Center Control B.
# J5029126 LED DIODE SML-012BCTT86 BLUE SMD D34 on Right Control B. 2
# J5029127 LED DIODE SML-012ECTT86 GREEN SMD D2,D10,D18,D26 on Right Control B. 9
D16,D23,D30,D50,D52 on Left Control B.
D31,D32,D33,D34,D35,D36,
D37,D38,D39,D40,D41,D42,
D43,D44,D45,D46,D47,D48 on Left Control B.
15339109 DIODE DAP 202K CHIP D13 on Audio B. 45
D35,D36,D37,D38,D39,D40,
D41,D42,D43,D44,D45,D46,
D47,D48,D49,D50,D51,D52,
D53,D54,D55,D56 on Right Control B.
D9,D10,D11,D12 on Center Control B.
01121323 DIODE DA-204U T-106 CHIP D3,D4,D5,D6,D7 on Main B. 5
00019356 DIODE 1SR139-400 T-32 D17 on Audio B. 1
01905134 SCHOTTKY DIODE MA7D49 D24 on Audio B. 1
RESISTOR
# J3919119 RESISTOR ARRAY EXB28V103JX RA18,RA21,RA24,RA26,RA41, 14
RA46,RA95,RA100,RA140,
RA141,RA142,RA143,RA144,
RA145 on Main B.
# J3919120 RESISTOR ARRAY EXB2HV330JV RA2,RA35,RA36,RA39,RA42, 14
RA113,RA114,RA115,RA116,
RA117,RA150,RA151,RA152,
RA153 on Main B.
# J3919121 RESISTOR ARRAY EXB2HV103V RA9,RA14,RA31,RA44,RA118, 6
RA119 on Main B.
# J3919122 RESISTOR ARRAY EXB28V330JX RA16,RA17,RA22,RA23,RA27, 19
RA29,RA33,RA37,RA38,RA45,
RA47,RA128,RA135,RA136,
RA137,RA138,RA139,RA154,
RA155 on Main B.
# J3919123 RESISTOR ARRAY EXB2HV104JV RA129,RA130,RA131 on Main B. 3
# J3919124 RESISTOR ARRAY EXB-2HV-R00-0V RA4,RA7,RA11,RA19,RA30, 9
RA32,RA34,RA146,
RA147on Main B.
# J3919125 RESISTOR ARRAY EXB-2HV-102-JV RA127 on Main B. 1
J3919104 RESISTOR ARRAY EXB-A10E-103-J RA3 on Right Control B. 2
RA3 on Left Control B.
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA65,RA134 on Main B. 2
J3919116 RESISTOR ARRAY EXB-V8V-220-JV RA106 on Main B. 8
RA1,RA2,RA4 on Right Control B.
RA1,RA2,RA4,RA5 on Left Control B.
01457145 RESISTOR ARRAY EXB-E10C-103-J RA1,RA8,RA40,RA43,RA50, 16
RA52,RA57,RA90,RA91,RA92,
RA93,RA96,RA112,RA120,
RA121,RA122 on Main B.
02456878 RESISTOR ARRAY EXB-2HV-220-JV RA108,RA124,RA125,RA126 on Main B. 4
J3809156 UNINFL. RES. 47 OHM 0.6W 5% R238,R239 on Card Protect B. 4
J3809162 METAL OXIDE RESIST.120 OHM 2W10% R66,R69,R93 on Audio B. 3
# J3809164 RESISTOR 3.3 OHM 10W +HEATSINK R228 on Audio B. 1
J3709168 RESISTOR 2010 1 OHM 1/2W 5% (MCR50) R126 on Audio B. 1
01783623 RESIST. 2010 10 OHM1/2W 5% R247 on Main B. 6
R6,R7,R118 on AudioB.
R15 on Right Control B.
# J3709170 RESISTOR 2010 0.22OHM 1/2w 5% (MCR50) R64 on Main B. 1
# J3709171 RESIST. 2010 22 OHM1/2W 5% R24 on Right Control B. 2
# J3709172 RESISTOR 2010 33 OHM 1/2W 5% (MCR50) R292 ON Main B. 15
R17,R18,R19,R20,R21,R22,
R23 on Right Control B.
15399989 RESIST. 2010 68 OHM1/2W 5% R19,R30 on Audio B. 2
POTENTIOMETER
00459901 ROT. POT. 10KB 14K 1230 VR1 on Volume B. 1
J3219110 ROT. POT. (10K) RK14J11A000G VR1 on Center Control B. 1
13289186 RK11K1130 10KB LM1-15C W/CLK VR2 on Volume B. 1
