E-50
21
CAPACITOR
15359774 POLYEST.COND. 0805 680P 5% C157,C171,C187,C203 on Main B. 4
J3629144 ELCTRL.COND. 470UF 16V AX C3 on Left Control B 1
13639154 ELECTRL.COND.-V 1000UF 16V C28,C142,C154,C189,C191 on Audio B. 5
13639153RI ELECTRL.COND.-V 470UF 16V C8 on Right Control B. 1
J3629122 ELECTRL.COND.-V 1000UF 25V C190 on Audio B. 1
J5369103 ELECTR.CAPACITOR RV2 100U 16V (SMD) C74,C235,C401 on Main B. 17
C1 on Right Control B.
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C145,C241,C491on Main B. 18
C41,C43,C44,C45,C65,C85,
C103,C125,C136,C221,C265,
C266,C306,C307 on Audio B
J5369107 ELECTR. COND. RV 330U 16V (SMD) C487 on Main B. 2
C141 on Audio B.
J5369105 ELECTR.CAPACITOR RV3 33U 16V (SMD) C21,C26,C31,C34,C51,C80, 27
C83,C84,C87,C168,C183,
C200,C202,C254,C255,C270,
C273,C456,C476 on Main B.
C36,C254,C255 on Audio B.
C2,C3,C7,C14 on Right Control B.
C2 on Left Control B.
J5369102 ELECTR.COND. RV2 47U 16V SMD C66,C69,C75,C80,C81,C87, 15
C116,C129,C155,C156,C161,
C267,C268,C269,C270 on Audio B.
J5369111 ELECTR. COND. RV2 10U 25V (SMD) C150,C157,C194,C195 on Audio B. 5
J5369108 CONDENSER SMD RV2 4.7U 25V ELET. ELNA C193 on Audio B. 2
C4 on Right Control B.
J5369106 ELECTR. COND. RV2 1U 50V (SMD) C56 on Main B. 5
C123,C124,C259,C308 on Audio B.
J3629137 ELECTR. COND. 33U 16V H.7 C3 on Volume B. 1
J3629172 CAPACITOR ECJ3FB1C105K C7,C24 on Audio B. 2
J3629173 ELECTR. CAPACITOR EEUFC1E181B 180UF 25V C2,C23 on Audio B. 2
INDUCTOR, COIL, FILTER
12449382RI NOISE SUP. PLT1-R53C FL4 on Audio B. 1
J2399104 CHIP NOISE SUP. EXCCL4532U1 L57,L58 on Audio B. 2
12449355 NOISE SUP. FBR07H850TB00 L40,L41 on Card Protect B. 2
01340834 FERRITE BEAD EXCML 20A390 L1,L2,L44,L45,L46,L47 on Audio B. 6
A 01787056 N1608Z 102T01 FERRITE-BEAD L1,L3,L16,L23,L24,L25, 43
L27,L28,L29,L30,L31,L32,
L33,L34,L37,L38,L50,L52,
L95,L96,L97,L98,L99,L100,
L101,L102,L103,L104,L105,
L106,L107 on Main B.
L8,L13,L37,L38,L48,L49,
L50,L52,L53,L54,L55,L56
L12,L14,R37,R43,R47,R75 on Audio B.
01909645 FERRITE BEAD EXCML16A270U L17,L19 on Main B. 2
A 01565578 NOISE SUPPRESSOR N1608Z601T01 L18,L21 on Main B. 2
A 01893634 INDUCTOR LQH43MN151K03L 150uH CHIP L12 on Main B. 2
L16 on Audio B.
# J2399113 INDUCTOR RCB0708P-100K-LF L3,L4,L5,L6 on Audio B. 4
CRYSTAL, RESONATOR
A 02561712 CEM X'TAL MA-406 12.500 MHZ TE24 X1,X3 on Main B. 2
00901912 X-TAL 24.576 MHZ MA-406 X2 on Main B. 1
00891801 QUARTZ 24 MHZ MA-406 X6 on Main B. 1
01340745 XTAL MA-406 12MHZ X4 on Main B. 1
J2389104 RESONATOR CSTLS4M00G53-BO (4MHZ) X2 on Audio B. 1
ENCODER
J3119105 ROTARY ENCODER EC12E24244F25 ENC1 on Encoder B. 1
CONNECTOR
J3439197 14P MALE CONNECTOR B14B-PH-K-S JST CN14 on Main B. 2
CN15 on Audio B.
13369567 4P MALE CONNECTOR B4B-PH-K-S (JST) CN13,CN30,CN33 on Main B. 4
CN37 on Audio B.
A 02900834 CONNECTOR SCAA1A4900 CN29 on Main B. 1
J3439206 15P MALE CONN. B15B-PH-K-S (JST) CN2 on Main B. 1
J3439208 6P MALE CONNECTOR(90) S6B-PH-K-S P.2 JST CN1 on Volume B. 1
J3429132 16P FEM.CONNECTOR AMP1.27 8-188275-6 CN9 on Right Control B. 2
CN1 on Center Control B.
J3439209 MALE CONNECTOR 5V.90°S5B-PH-K-S P.2 JST CN1 on Encoder B. 1
04123090 CONNECTOR CFP1504-0401F CN3 on Center Control B. 1
00451401 16P FEM. CONNECTOR AMP 1.27 CN35,CN36 on Main B. 2
13419676RI 8P MALE CONN. P/2.5 MOLEX CN38 on Audio B. 1
13369688RI 4P MALE CONN. P 2.5 M CN1 on Power Switch B. 2
CN16 on Audio
J3439125 5P MALE CONNECTOR P.2 M CN21 on Main B. 1
J3439143 34P MALE CONN. P. 1.27 M CN11 on Main B. 1
J3439123 6P MALE CONN. P. 2 M 90 CN3 on Volume B. 1
J3429120 3P MALE CONNECTOR P.2 M CN32 on Main B. 2
13369568 B3B-PH-K-S CONNECTOR CN12 on Main B. 1
13369566 B6B-PH-K-S CONNECTOR CN7,CN18 on Main B. 4
