4-1 Practicing Cutting Using the Test-use Material
Chapter 4: Performing Cutting
38
2. Switch on the power to the machine and make it ready to receive data from the computer.
➊
Press the power button.
The power comes on.
➋
Press to choose "PIECE."
➌
Press .
The cutting carriage moves to the left edge
and the material moves forward and back-
ward.
Then, the cuttable width and length appear
on the display.
After operation stops, be sure to check and make sure the material has not come loose.
SELECT SHEET
* PIECE
W : 175mm
L : 233mm
* These values are examples for
reference only. The actual width
and length vary according to the
positions of the pinch rollers
and other factors.
Cutting carriage
Width
Length
OK Not OK

Roland GX-24 Specifications

General

Cutting Speed	Up to 20 inches/sec (500 mm/sec)
Distance Accuracy	±0.004 inches (±0.1 mm) or less
Repeatability	±0.1 mm (0.0004 in.) or less
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 to 40°C (41 to 104°F)
Operating Humidity	35 to 80% RH (non-condensing)
Software Resolution	0.025 mm/step (0.001 in./step)
