Roland GX-24 User Manual

4-1 Practicing Cutting Using the Test-use Material
Chapter 4: Performing Cutting
47
➍
Click the [Size] tab.
➎
(*)Click [Get from Machine].
The cuttable range is displayed.
➏
Click [OK].
➐
Click [OK] again to close the [Cutting
setup] window.
The white area is the cutting
range. Text or shapes drawn
outside this range are not cut.
The cutting range has now been set.
* If you're using a serial connection, en-
ter manually the values of the width
(W) and length (L) displayed on the
machine's display.

Roland GX-24 Specifications

General

Cutting Speed	Up to 20 inches/sec (500 mm/sec)
Distance Accuracy	±0.004 inches (±0.1 mm) or less
Repeatability	±0.1 mm (0.0004 in.) or less
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 to 40°C (41 to 104°F)
Operating Humidity	35 to 80% RH (non-condensing)
Software Resolution	0.025 mm/step (0.001 in./step)
