Roland JUPITER-X User Manual

JUPITER-X Owner’s Manual Ver. 3.0 and later
29
Parameter
[1] knob
Value
[2] knob
Explanation
Wheel1
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the
[WHEEL 1] wheel.
Wheel2 Source
SCENE, SYS
Specifies whether the function assigned
to the [WHEEL 2] wheel follows the setting
of the currently selected scene (SCENE) or
follows the system setting (SYS).
Wheel2
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the
[WHEEL 2] wheel.
SYSTEM - MIC IN
MIC IN
Mic In Gain
-24.0–+24.0 [dB] Adjusts the input level of the MIC IN jack.
Mic Power
OFF, ON
If this is “ON”, plug-in power (5 V) is supplied
to the MIC IN jack.
Rev Send Lev
0–127
Specifies the amount of reverb that is applied
to the mic input.
Cho Send Lev
0–127
Specifies the amount of chorus that is applied
to the mic input.
Dly Send Lev
0–127
Specifies the amount of delay that is applied
to the mic input.
Mic Thru
OFF, ON
If you want the mic to be cut when the
vocoder is off, turn this “OFF”.
NS
NS Switch
OFF, ON
Switches the noise suppressor on/off.
The noise suppressor is a function that
suppresses noise during periods of silence.
NS Threshold
-96–0 [dB]
Adjusts the volume at which noise
suppression starts to be applied.
NS Release
0–127
Adjusts the time from when noise
suppression starts until the volume reaches 0.
COMP
CompSwitch
OFF, ON
Specifies whether the mic compressor (a
compressor applied to the mic input) is used
(ON) or not used (OFF).
CompAttack
0.1, 1, 2, ..., 100
[ms]
Specifies the time from when the input to
the mic compressor exceeds the Comp Thres
level until the volume is compressed.
CompRelease
10, 20, ..., 1000
[ms]
Specifies the time from when the input to the
mic compressor falls below the Comp Thres
level until compression is no longer applied.
CompThreshold
-60–0 [dB]
Specifies the level at which the mic
compressor starts applying compression.
CompRatio
1: 1, 2: 1, …4: 1,
8: 1, 16: 1, 32: 1,
INF: 1
Specifies the compression ratio for the mic
compressor.
CompKnee
0–30 [dB]
Smooths the transition until the mic
compressor starts to be applied.
Higher values produce a smoother transition.
CompOutGain
-24.0, -23.5, … 0,
…, +24.0 [dB]
Specifies the output volume of the mic
compressor.
SYSTEM - MIDI
MIDI
Ctrl Ch
1–16, OFF
Specifies the MIDI receive channel on which
MIDI messages (program change and bank
select) from an external MIDI device can be
received to switch programs.
If you don’t want programs to be switched
from a connected MIDI device, turn this “OFF”.
Ctrl Src Sel
SYS SysCtrlSrc1–4 are used for tone control.
SCENE
The scene’s CtrlSrc1–4 settings are used for
tone control.
Parameter
[1] knob
Value
[2] knob
Explanation
S3 Func
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the [S3]
button.
S3 Mode
LATCH,
MOMENTARY
Specifies how the button operates.
SLIDER Func
SL1 Source
SCENE, SYS
Specifies whether the function assigned
to the SL1 slider follows the setting of the
currently selected scene (SCENE) or the
system setting (SYS).
SL1
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the [SL1]
slider.
SL2 Source
SCENE, SYS
Specifies whether the function assigned
to the SL2 slider follows the setting of the
currently selected scene (SCENE) or the
system setting (SYS).
SL2
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the [SL2]
slider.
PEDAL Func
Hold Source
SCENE, SYS
Specifies whether the function assigned to
the pedal connected to the HOLD jack follows
the setting of the currently selected scene
(SCENE) or the system setting (SYS).
Hold
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the pedal
connected to the HOLD jack.
Hold Pole
STANDARD,
REVERSE
Specifies the polarity of the pedal connected
to the HOLD jack.
Ctrl Source
SCENE, SYS
Specifies whether the function assigned to
the pedal connected to the CTRL jack follows
the setting of the currently selected scene
(SCENE) or the system setting (SYS).
Ctrl
For the values, refer
to “List of functions
that can be assigned
to the controllers”
Specifies the function assigned to the pedal
connected to the CTRL jack.
PART Btn Asgn
1-5
1-5+ (S)
6-10
6-10+ (S)
11-15
11-15+ (S)
Assign the function of the [1]–[5] ([6]–[10]) buttons and their
function when pressed while holding down the [SHIFT] button.
No Assign Nothing is assigned.
PartSel
Specifies the current part that is controlled
from the panel or in the screen. The part
played by the keyboard does not change.
Part+KeySw
Simultaneously operates the current part and
the Keyboard SW, allowing you to play the
selected part from the keyboard. By pressing
multiple parts simultaneously, you can turn
the Keyboard SW on for multiple parts.
KeySw
Specifies the keyboard switch, switching the
part that is played from the keyboard.
PartSw
Switches on/off whether the part produces
sound. You can use this in a DJ-like manner to
add or remove parts while you perform.
ArpSw
Specifies whether each part is played by the
arpeggio.
EfxSw
From the left side, the buttons switch MFX,
DRIVE, REV, DLY, and CHO on/off for all parts
simultaneously.
Wheel Func
Wheel1 Source
SCENE, SYS
Specifies whether the function assigned
to the [WHEEL 1] wheel follows the setting
of the currently selected scene (SCENE) or
follows the system setting (SYS).

Roland JUPITER-X Specifications

Power

power supply	AC 117–240 V, 50/60 Hz
power consumption	20W

Sound and Effects

preset tones	4, 000 or greater
user tones	256
drum kits	90 or greater

Connectivity

bluetooth profile support	A2DP, GATT
headphones jacks	Stereo miniature phone type, Stereo 1/4-inch phone type
main out jacks	1/4-inch phone type, XLR type

Weight and Dimensions

width	1, 090 mm
depth	447 mm
height	119 mm
weight	16.9 kg
