Tone Selection

Group Buttons (A-D)

There are 16 Groups of 64 Tones in the Kiwi-3P matrix. Each group is made up of 8

Banks of 8 Tones giving a total of 1024 Tones (16x8x8). As there are only 4 Group

buttons there are 4 layers of Groups. The current Group layer is changed by

pressing the currently selected Group button again. For example to change from

Group A to Group E press the Group A button when it is lit. One more press of the

same button will select Group I and another press will select Group M. Another

press will return you to Group A.

The Group lights will show which Group is selected as follows

Group Layer 1 (Groups A-D) Selected Group On Steady - others Off

Group Layer 2 (Groups E-H) Selected Group On Flashing - others Off

Group Layer 3 (Groups I-L) Selected Group Off - others On Steady

Group Layer 4 (Groups M-P) Selected Group Flashing - others On Steady

Bank and Tone Buttons (1-8)

The buttons 1-16 have been split into two groups of 8. The buttons 1-8 are the BANK Selection buttons and the buttons

9-16 are the TONE Selection buttons 1-8. See the Front Panel layout on page 5. All tones have a Group, Bank and Tone

ID. The first tone has the location A:1:1, the second is A:1:2 and the last is P:8:8.

The Group, Bank and Tone buttons will light to show the selection.

Note - The memory protection switch on the rear of the 3P will prevent memory writing. The write button will not function

if the rear panel switch is in the middle position.

All the Tone lights will flash once if a write is attempted with the protect on.

You can only select one tone at a time

All tones on all banks can be edited and programmed (1024 in total)

Roland KIWI-3P User Manual
