27
4(F) = 32nd note triplets (2 Clocks/Step)
5(F) = 64th note triplets (1 Clocks/Step)
Clock source is Master Clock
(F)= Flash
Seq Step Timing D:3:4 1 = Half Note (48 Clocks/Step)
2 = Quarter note (24 Clocks/Step)
3 = 8th note (12 Clocks/Step)
4 = 8th note, half swing (14,10 Clocks/Step)
5 = 8th note, full swing (16,8 Clocks/Step)
6 = 8th note triplets (8 Clocks/Step)
7 = 16th note (6 Clocks/Step)
8 = 16th note, half swing (7,5 Clocks/Step)
1(F) = 16th note, full swing (8,4 Clocks/Step)
2(F) = 16th note triplets (4 Clocks/Step)3
3(F) = 32nd note (3 Clocks/Step)
4(F) = 32nd note triplets (2 Clocks/Step)
5(F) = 64th note triplets (1 Clocks/Step)
Clock source is Master Clock
(F)= Flash
GLOBAL – Midi and General Settings
Midi In Channel GA:1:1 1-8 = Channel 1-8 (Midi 0-7)
9-16 = Channel 1-8(F) (Midi 8-15)
All Tone Lights will flash for OMNI
(F)= Flash
Midi Out Channel GA:1:2 1-8 = Channel 1-8 (Midi 0-7)
9-16 = Channel 1-8(F) (Midi 8-15)
(F)= Flash
Seq Midi Out Channel GA:1:3 1-8 = Channel 1-8 (Midi 0-7)
9-16 = Channel 1-8(F) (Midi 8-15)
(F)= Flash
Enable Midi CC GA:1:4 1 = Off
2 = Midi CC Receive Enabled
3 = Midi CC Transmit Enabled
4 = Midi CC Receive & Transmit Enabled
Enable Midi Sysex Receive GA:1:5 1 = Midi Sysex Receive Disabled
2 = Midi Sysex Receive Enabled
Note – Sysex is Enabled everytime the Kiwi-3P Matrix
is powered on so editors will work.
Enable Program Change Command GA:1:6 1 = Off
2 = Midi PC Receive Enabled
3 = Midi PC Transmit Enabled
4 = Midi PC Receive & Transmit Enabled
Enable Midi Soft Through
note - real time midi commands will
always pass and GA:1:7 will have no
effect
GA:1:7 1 = Stop All
2 = Pass All
3 = Pass only nonCC
4 = Stop only CC we have used
Enable Midi Clock Generation GA:1:8 1 = Midi Clock not generated
2 = Midi Clock Generated from Internal
Master Clock Source GA:2:1 1 = Internal
2 = Midi
www.kiwitechnics.com Kiwi-3P Matrix Upgrade User Manual v1.2
