Roland KIWI-3P - Matrix Source and Destination List

60
Table 2
Matrix Source and Destination List
Matrix Source Types Matrix Destination Types
0 O 0 O
1 Bend Up 1 DCO1 Freq
2
2 Bend Down 2 DCO2 Freq
2
3 Bend Full 3 All DCO Freq
2
4 Midi Mod 4 DCO1 Range
3
5 Key Down Velocity
1
5 DCO1 Wave
3
6 Key Up Velocity
1
6 DCO1 LFO Level
3
7 Key Note
1
7 DCO1 ENV Level
3
8 LFO1 (bipolar) 8 DCO1 Pulse Width
3
9 LFO1 (unipolar) 9 DCO1 PWM
3
10 LFO2 (bipolar) 10 DCO2 Range
3
11 LFO2 (unipolar) 11 DCO2 Wave
3
12 LFO3 (bipolar) 12 DCO2 LFO Level
3
13 LFO3 (unipolar) 13 DCO2 ENV Level
3
14 ENV1
1
14 DCO2 Pulse Width
3
15 ENV2
1
15 DCO2 PWM
3
16 ENV3
1
16 Mix Level
3
17 MidiCC#1 17 DCO Detune
3
18 MidiCC#2 18 VCF High Pass
3
19 MidiCC#3 19 VCF Cuto
2
20 MidiCC#4 20 VCF Resonance
3
21 MidiCC#5 21 VCF LFO Level
3
22 MidiCC#6 22 VCF ENV Level
3
23 Midi Channel After Touch 23 VCF Key Level
3
24 Midi Note After Touch
1
24 VCA Level
2
25 Keyboard Gate 25 VCA LFO Level
3
26 Midi Hold 26 Portamento Rate
3
27 Hold Pedal 27 LFO1 Rate
3
28 LFO Trig Button 28 LFO2 Rate
3
29 LFO3 Rate
3
30 ENV1 Attack Rate
3
31 ENV1 Decay Rate
3
32 ENV1 Release Rate
3
33 ENV2 Attack Rate
3
34 ENV2 Decay Rate
3
35 ENV2 Release Rate
3
36 ENV3 Attack Rate
3
37 ENV3 Decay Rate
3
38 ENV3 Release Rate
3
39 Chorus Rate
3
¹ = Source is per voice
2
= Destination is per voice
3
= Destination is used in all voices
www.kiwitechnics.com Kiwi-3P Matrix Upgrade User Manual v1.2
