41
Midi Data
Function Transmitted Recognized Notes
Basic Channel 1-16 1-16 If Omni selected the 3P will recognize any
midi channel
Note Number 24(C1)-108(C8) 0-127 Notes that are received outside the JX-3P
range of 24-108 are transposed to the
nearest octave within range.
Mode X X Voice Modes need to be changed using Midi
Control or Sysex commands
Velocity
Note On
Note Off
O
X
O
X
All keys sent from the JX-3P have a velocity
set by the Global Parameter A4 (or midiCC
107)
Aftertouch
Keys
Channels
X
X
X
O
Due to the small number of keyboards
supporting Key AT only Channel AT has been
implemented.
Pitch Bender O O Midi & internal bends are additive within
the 3P. Midi bend input is effected by the
Range switch.
Control Change O O Only if Midi CC option is Enabled. See
Control Change Tables for details
Program Change X 0-127 If CC0, CC32 is 0,0 then 0-63 selects Tone
Bank 1, 64-127 Selects Tone Bank 2
If CC0, CC32 is 0,1 then 0-63 selects Tone
Bank 3, 64-127 Selects Tone Bank 4
System Exclusive O O Only if Midi Sysex option is Enabled - See
Sysex Table for details
System Real Time Clock
Commands
O O Will Transmit from Seq Clock if Clock Output
is enabled. Input clocks passed through to
midi out unaltered. Recognized within the 3P
only if the clock source has been set to
midi on the Pattern, Arp or Sequence clocks
Modulation O O Will adjust patch value(s) as a temporary
effect if enabled.
Notes X=No O=Yes
Supported Midi
Messages
Status Second Third Notes
Note Off $8n (128-143) $kk $yy n = 0-15 midi channel
kk = note number (0-127) -outside range 24-108 are
ignored
yy = Don't care (ignored)
Note On $9n (144-159) $kk $yy n = 0-15 midi channel
kk = note number (0-127)-outside 24-108 are transposed
to the nearest Octave
yy = 0=Off, 1-127 = Note Velocity.
Continuous Controllers $bn (160-191) $kk $yy n = 0-15 midi channel
$kk & $yy see CC table
Program Change $cn (192-207) 0-127 n = 0-15 midi channel
If CC0, CC32 is 0,0 then
0-63 selects Tone Bank 1, 64-127 Selects Tone Bank 2
If CC0, CC32 is 0,1 then
0-63 selects Tone Bank 3, 64-127 Selects Tone Bank 4
Channel Aftertouch $dn (208-223) $kk --- n = 0-15 midi channel
kk = Channel Pressure (0-127)
Pitch Bend $en (224-239) $kk $yy n = 0-15 midi channel
kk = Least Significant 7 bits
yy = Most Significant 7 bits
Note $xx = hex number
www.kiwitechnics.com Kiwi-3P Matrix Upgrade User Manual v1.2
