42
Playing Back
The following describes how to connect devices with digital input ports, such as mixers, speakers, or
recording devices, to the [DIGITAL OUT] jack of R-44.
fig.basic-disp.eps
The sampling frequency of the project playing back will be the
sampling frequency of the audio output from the digital output
connector.
1. Turn off the power to the R-44.
2. Turn off power to the device with the digital input port.
3. Connect the [DIGITAL OUT] jack to the digital input connector of the device with digital input.
* You will need a separately available coaxial cable (not included) to connect your digital device to the [DIGITAL OUT]
jack.
4. Turn on the R-44’s power.
5. Turn on power to the device with the digital input port.
* You cannot adjust the volume of the digital signal on the R-44.
Connecting a Device Having a Digital Input Port
