Roland R-44

58
Setting the Color of Sound (Effects Settings)
1: 3-Band EQ
2: Graphic EQ
3: Noise Gate
Effects
No.
Parameter
name
Range of values
Default
values
Explanation
1 MID-F
200 Hz, 250 Hz, 315 Hz,
400 Hz, 500 Hz, 630 Hz,
800 Hz, 1 kHz, 1.25 Hz,
1.6 kHz, 2 kHz, 2.5 kHz,
3.15 kHz, 4 kHz, 5 kHz,
6.3 kHz
1 kHz
Specifies the center frequency of the
mid-range equalizer.
2 MID-Q 0.5, 1.0, 2.0, 4.0, 8.0 2.0
Sets the range of the region centered
on the Mid Freq for which the gain
will change. Higher values narrow
the region in which the change oc-
curs.
3 LOW -12 dB–0 dB–+12 dB 0 dB
Adjusts the gain of the low-range
equalizer.
4 MID -12 dB–0 dB–+12 dB 0 dB
Adjusts the gain of the mid-range
equalizer.
5 HIGH -12 dB–0 dB–+12 dB 0 dB
Adjusts the gain of the high-range
equalizer.
6 LEVEL 0–120 100 Adjusts the overall volume.
No.
Parameter
name
Range of values
Default
values
Explanation
1 125 Hz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 125 Hz.
2 250 Hz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 250 Hz.
3 500 Hz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 500 Hz.
4 1 kHz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 1 kHz.
5 2 kHz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 2 kHz.
6 4 kHz -12 dB–0 dB–+12 dB 0 dB Adjusts the gain at 4 kHz.
7 Level 0–120 100 Adjusts the overall volume.
No.
Parameter
name
Range of values
Default
values
Explanation
1 LO-CUT
OFF, 40 Hz, 55 Hz, 63 Hz,
80 Hz, 100 Hz, 125 Hz,
160 Hz, 200 Hz, 250 Hz,
315 Hz, 400 Hz, 500 Hz,
630 Hz, 800 Hz, 1 kHz
100 Hz
Cuts unwanted low-frequency noise
such as wind.
2 THRESHOLD OFF, 1–100 20
Specifies the volume threshold be-
low which the sound will be cut.
3 LEVEL 0–120 100 Adjusts the overall volume.
