MIDI Implementation
Model: RD-700SX (Digital Piano)
Date: Nov. 1, 2004
Version: 1.00
1. Receive data
■
Channel Voice Messages
●
Note off
Status
2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
* Some instruments are not received in Rhythm set.
* The velocity values of Note Off messages are ignored.
●
Note on
Status
2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
●
Control Change
❍
Bank Select (Controller number 0, 32)
Status
2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received when the Rx Bank Select (EDIT:Part Parameter:Rx Bank Select) is OFF.
* The SETUP, Rhythms, and Tones corresponding to each Bank Select are as follows.
* The SRX series corresponding to each Bank Select are to see the SRX series owner’s
manual.
BANK SELECT | PROGRAM | GROUP | NUMBER
MSB | LSB | NUMBER | |
-----+---------+-----------+----------------------+-----------
000 | | 001 - 128 | GM Tone |
: | | | |
032 | | 001 - 128 | GM Tone |
085 | 000 | 001 - 100 | SETUP | 001 - 100
086 | 064 | 001 - 005 | Rhythm Set | 219 - 223
087 | 064 | 001 - 020 | Tone (PIANO) | 001 - 020
| 065 | 001 - 021 | Tone (E.PIANO) | 021 - 041
| 066 | 001 - 021 | Tone (CALV/MALLET) | 042 - 062
| 067 | 001 - 020 | Tone (ORGAN) | 073 - 092
| 068 | 001 - 022 | Tone (STRINGS) | 093 - 114
| 069 | 001 - 020 | Tone (PAD) | 115 - 134
| 070 | 001 - 038 | Tone (GTR/BASS) | 135 - 172
| 071 | 001 - 024 | Tone (BRASS/WINDS) | 173 - 196
| 072 | 001 - 022 | Tone (VOICE/SYNTH) | 197 - 218
| : | | : |
092 | 000 - | 001 - | SRX Rhythm | 001 -
| : | | : |
093 | 000 - | 001 - | SRX Patch | 001 -
| : | | : |
112 | 000 | 001 - 010 | TW-Organ | 063 - 072
120 | | 001 - 057 | GM2 Rhythm | 224 - 232
121 | 000 - | 001 - 128 | GM2 Tone | 233 - 488
❍
Modulation (Controller number 1)
Status
2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
* Not received when the Rx Modulation (EDIT:Part Parameter:Rx Modulation) is OFF.
❍
Portamento Time (Controller number 5)
Status
2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* The Portament Time parameter (Tone Info:Portament Time) will change.
❍
Data Entry (Controller number 6, 38)
Status
2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
❍
Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
* Not received when the Rx Volume (EDIT:Part Parameter:Rx Volume) is OFF.
* The Part Level parameter will change.
❍
Panpot (Controller number 10)
Status
2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),
* Not received when the Rx Pan (EDIT:Part Parameter:Rx Pan) is OFF.
* The pan parameter (EDIT:Part Parameter:Pan) will change.
❍
Expression (Controller number 11)
Status
2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
❍
General Purpose Controller 1 (Controller number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number:0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍
Hold 1 (Controller number 64)
Status
2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
* Not received when the Rx Hold-1 (EDIT:Part Parameter:Rx Hold-1) is OFF.
❍
Portamento (Controller number 65)
Status
2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* The Portamento Sw parameter (Tone Info:Portament Sw) will change.
❍
Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍
Soft (Controller number 67)
Status
2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍
Legato Foot Switch (Controller number 68)
Status
2nd byte 3rd byte
BnH 44H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
