Roland S-1

MIDI implementation chart
74
Control Change
Explanation
10
Pan
11
Expression Pedal
12
LFO WAVE FORM (LFO [WAVE FORM] knob)
13
OSC LFO (OSCILLATOR [LFO] knob)
14
OSC RANGE (OSCILLATOR [RANGE] knob)
15
OSC PULSE WIDTH ([SHIFT] button + [PWM DEPTH] pad) ([SHIFT] +OSCILLATOR [ ] knob)
16
OSC PWM SOURCE ([SHIFT] button + [PWM SRC] pad)
17
LFO MODULATION DEPTH ([SHIFT] button + pad [15] (MENU): LFO Modulation Depth)
18
OSC BEND SENS ([SHIFT] button + pad [15] (MENU): Oscillator Bend Sens)
19
OSC LEVEL (OSCILLATOR [ ] knob)
20
OSC LEVEL (OSCILLATOR [ ] knob)
21
OSC SUB OSC LEVEL (OSCILLATOR [SUB] knob)
22
OSC SUB OCT TYPE ([SHIFT] button + [SUB OCT] pad)
23
OSC NOISE LEVEL (OSCILLATOR [NOISE] knob)
24
FILTER ENVELOPE (FILTER [ENV] knob)
25
FILTER LFO (FILTER [LFO] knob)
26
FILTER KEYBOARD FOLLOW ([SHIFT] button + pad [7] (FILTER KYBD) pad) ([SHIFT] button +FILTER [ENV] knob)
27
FILTER BEND SENS ([SHIFT] button + pad [15] (MENU): Filter Bend Sens)
28
AMP ENVELOPE MODE SW ([SHIFT] button + [AMP] pad)
29
ENV TRIGGER MODE ([SHIFT] button + [ENV TRG] pad)
30
ENV SUSTAIN (ENV [SUSTAIN] knob)
31
PORTAMENTO MODE ([SHIFT] button + [PORTA ON] pad)
64
Damper Pedal
65
PORTAMENTO
71
FILTER RESONANCE (FILTER [RESO] knob)
72
ENV RELEASE (ENV [RELEASE] knob)
73
ENV ATTACK (ENV [ATTACK] knob)
74
FILTER FREQUENCY (FILTER [FREQ] knob)
75
ENV DECAY (ENV [DECAY] knob)
76
FINE TUNE ([SHIFT] +OSCILLATOR [RANGE] knob)
77
TRANSPOSE SW ([SHIFT] button + [STEP] (KEY TRANSPOSE) button)
78
NOISE MODE ([SHIFT] button + pad [15] (MENU): Noise Mode) ([SHIFT] + OSCILLATOR [NOISE] knob)
79
LFO MODE ([SHIFT] button + pad [15] (MENU): LFO Mode) ([SHIFT] +LFO [RATE] knob)
80
POLY MODE ([SHIFT] button + [POLY] pad: Poly Mode)
81
CHORD VOICE 2 SW ([SHIFT] button + [POLY] pad: Voice 2 SW)
82
CHORD VOICE 3 SW ([SHIFT] button + [POLY] pad: Voice 3 SW)
83
CHORD VOICE 4 SW ([SHIFT] button + [POLY] pad: Voice 4 SW)
85
CHORD VOICE 2 KEY SHIFT ([SHIFT] button + [POLY] pad: Voice 2 Key Shift)
86
CHORD VOICE 3 KEY SHIFT ([SHIFT] button + [POLY] pad: Voice 3 Key Shift)
87
CHORD VOICE 4 KEY SHIFT ([SHIFT] button + [POLY] pad: Voice 4 Key Shift)
89
REVERB TIME ([SHIFT] + [REVERB] knob)
90
DELAY TIME ([SHIFT] + [DELAY] knob)
91
REVERB LEVEL ([REVERB] knob)
92
DELAY LEVEL ([DELAY] knob)
93
CHORUS ([SHIFT] button + pad [15] (MENU): Chorus)
102
OSC DRAW MULTIPLY ([SHIFT] button + pad [5] (OSC DRAW): MULTIPLY) ([SHIFT] + OSCILLATOR [ ] knob)
103
OSC CHOP OVERTONE ([SHIFT] button + pad [6] (OSC CHOP): OVERTONE) ([SHIFT] + OSCILLATOR [LFO] knob)
104
OSC CHOP COMB ([SHIFT] button + pad [6] (OSC CHOP): COMB) ([SHIFT] + OSCILLATOR [SUB] knob)
105
LFO KEY TRIGGER ([SHIFT] button + pad [15] (MENU): LFO Key Trigger)
106
LFO SYNC ([SHIFT] button + [MENU] pad: LFO Sync) ([SHIFT] +LFO [WAVE FORM] knob) (Ver.1.02)
107
OSC DRAW SW ([SHIFT] button + pad [5] (OSC DRAW): SW) ([SHIFT] + OSCILLATOR [ ] knob)
