Rollmatic C42 - Page 36

Taglierina - Slicer
SCHEMA ELETTRICO
ELECTRIC DIAGRAM
ALLEGATO 2
C42/52, C42S/52S, G42
13/07/2010 Rev. A
2/2
Data emissione: 13/07/2010
Date of issue:
13/07/2010
DESCRIZIONE -
DESCRIPTION
TIPO -
PART NUMBER
EL08 Scheda control -
Electronic
board
EL08
SB1 Pulsante Emergenza -
Emergency button
A.B. 800FP-MT44
SB1 Base pulsante -
Base button
A.B. 800F-ALP
SB1 Contatto –
Contact
NC A.B. 800F-X01
SB2 Pulsante start –
Start button
A.B. 800FP-LF3
SB2 Base pulsante -
Base button
A.B. 800F-ALP
SB2 Contatto –
Contact
NO A.B. 800F-X10
HL1 Lampada -
Indicator light
A.B. 800F-D0C + BA9S 30v 2W
SQ1 Microinterruttore –
Microswitch
XCKN2102G11
FU1 Fusibile –
Fuse
5x20 500mA
FU2/3/4 Fusibile –
Fuse
6,3x32 16A
FU5/6 Fusibile –
Fuse
6,3x32 500mA
