Rosco Maximizer 3B Asphalt Distributor 10-91
Illustrated Parts List (IPL)
Enviroflush System Parts List
Item
No. Part Number Qty. Description Remarks
21810 1 Enviro Flush System
1 21701 1 •Tank Wldmt,Diesel
2 36940 1 •Cap,Fuel,4.0 Npt,Al,W/Gasket
3 5499 REF •Vlv,Drain Cock,.250 Npt (Part Of Diesel Burner)
4 6352 REF •Hose,08,Push-On,250 (Part Of Diesel Burner)
5 35569 REF •Vlv,Check,08 Npt,Swing (Part Of Flush Tank)
6 1003147 2 •Valve,Solenoid, 1.00 Ball
7 36999 1.83’ •Hose,1.00 Id,Hot Asphalt
-15 17934 1 •Flush Tank System
Attaching Parts
-1503 21701 1 ••Tank Wldmt,Diesel
-1504 31971 1 ••Fitt,90 04Mp-04Hb,Crimped
-1506 33328 2 ••Fitt,90 08Mp-08Hb,Crimped
-1507 35569 1 ••Vlv,Check,08 Npt,Swing
-1508 36940 1 ••Cap,Fuel,4.0 Npt,Al,W/Gasket
-1509 5499 1 ••Vlv,Drain Cock,.250 Npt
-1511 91315 1 ••Pipe,Tbe,08X83.00
-1512 91316 1 ••Pipe,Tbe,08X55.00
-1513 9672 4 ••Bracket,Pipe,0.50
-1514 99535 2 ••Pipe,Plug,04Mp,Sq Hd,Mi
-1515 99980 1 ••Pipe,Bush,08Mp-04Fp,Stl
-1516 99990 1 ••Pipe,Bush,16Mp-08Fp,Stl
-1517 X427 1 ••Fitt,Str 08Mp-08Hb,Crimped
-21 15944 2 •Plate,Tapped
-22 21813 2 •Brkt,Pipe Support
-23 33167 4 •Clamp,Hose,.81-1.75,Worm,#20
-24 33277 1 •Clamp,Hose,# 04
-25 5347 2 •Hose,04,Push-On,Low Pressure
-26 70036 4 •Fitt,Str 16Mp-16Hb,Crimped
-27 70444 1 •Pipe,Plug,2.00Mp,Sq Hd,Mi
-28 71622 4 •CSHH,.375-16X.88,Gr5
-29 80162 4 •Washer,Lock,.375
-30 80142 8 •Washer,Flat,Uss,.375
-31 99507 1 •Pipe,45,16Fp,Mi
-32 99514 1 •Pipe,90,16Fp,Mi
-33 99539 1 •Pipe,Plug,16Mp,Sq Hd,Mi
-100 10553 1 •Decal,Solvent Tank
