Rosco Maximizer 3B Asphalt Distributor 6-11
Operation
Table 6-3. Tank Contents Chart to Ensure Flue Tube Coverage
TANK SIZE AMOUNT W/ ONE FLUE AMOUNT W/ TWO FLUES
GALLONS LITERS GALLONS LITERS GALLONS LITERS
1000 - 1100 3785 - 4164 500 1893 700 2650
1250 - 1350 4732 - 5110 600 2271 900 3407
1500 - 1600 5678 - 6057 650 2461 1000 3785
1750 - 1850
(10 ft Tank)
6625 - 7003
(3 m Tank)
650 2461 1000 3785
1750 - 1850
(14 ft Tank)
6625 - 7003
(4 m Tank)
750 2839 1150 4353
1950 - 2000 7382 - 7571 750 2839 1150 4353
2500 - 2600 9464 - 9842 900 3407 1450 5489
3000 - 3100 11,356 - 11,375 1000 3785 1600 6057
3500 - 3600 13,249 - 13,627 1000 3785 1600 6057
4000 - 4100 15,142 - 15,520 1150 4353 1800 6814
(Figure 6-1), (see Tank Circulate Mode in Section
6).
Operating the burners without
circulating the product can create explosive fumes.
If the product can not be circulated after 15 minutes
of heating, the fuel to the burners must be turned off,
while leaving the blowers running (15 minutes ON, 15
minutes OFF). Do not try to heat material again for
30 minutes.
9. Set asphalt pump to the forward position at a ow of
75 - 100 GPM.
10. Turn the fuel and blower switches on the fender
controls OFF.
NOTE: Burner Control switch is a momentary switch and
will return to the OFF position. An icon will display
on the screen when the Burner Control switch
has enabled the burner system controls.
11. Turn the Burner Control switch ON.
12. Turn lower burner blower switch on the fender
controls ON. Wait 1 to 2 minutes to purge residual
gas fumes from system before proceeding.
13. Turn lower burner fuel switch on the fender controls
to the ON position.
NOTE: The burner should light. If it does not start
immediately, shut OFF fuel, run blower to clear
fuel from ue and retry in 1 to 2 minutes.
If the fuel is not cleared from the ue,
the fuel may backre through the burner when the
operator tries to relight it. The operator could get
burned.
DO NOT SMOKE around the machine.
Fuel, asphalt material and the fumes from both
can explode when exposed to ame or heat from
smoking or other sources.
Hot material will turn water into steam
and can cause an explosion.
3. Be sure that ue tubes are covered by at least 8
inches of material. Read the tank dipstick. If the
amount in the tank is less than the recommended
amount in Table 6-3. Tank Contents Chart to
Ensure Flue Tube Coverage, do not use the
burners. Using the burners without enough material
in the tank will cause damage to the ue tubes and
could cause an explosion.
Never operate the burners if the ue
tubes are not covered with at least 8” of material. The
ue tubes can become red hot and ignite the vapors
causing an explosion.
4. Start and run the engine at 1000 to 1200 RPM,
engage PTO (if equipped). This provides power to
the asphalt pump.
5. Do not load, unload, transport or spray while
burners are operating.
6. Turn the Plus One Controller Master switch ON to
activate the system, (Figure 5-2,1).
7. Set the Plus One Controller to the required
temperature for the material being used, (Figure
6-11).
8. Push the Mode Selection Button 2 - Tank Circulate
Return to
Last Viewed
Return to
Thumb Index
