Rosemount 1495 - Page 19

Reference Manual
00809-0100-4792, Rev CA
August 2010
3-7
Rosemount 1495, 1496
1495PC Orifice Paddle Type
(Paddle, Square edged, Concentric)
1495PG Orifice Paddle Type
(Paddle, Square edged, Concentric, Spiral finish)
Line
Size
Diameter for Paddle Type
(1)
Handle
Length
Handle
Width
150# 300# 600# 900# 1500# 2500#
2-in. 4.125
(104.78)
4.375
(111.13)
4.375
(111.13)
5.625
(142.875)
5.625
(142.875)
5.750
(146.05)
4.0
(101.6)
1.00
(25.4)
2
1
/2-in. 4.875
(123.82)
5.125
(130.18)
5.125
(130.18)
6.500
(165.1)
6.500
(165.1)
6.625
(168.275)
4.0
(101.6)
1.00
(25.4)
3-in. 5.375
(136.53)
5.875
(149.23)
5.875
(149.23)
6.625
(168.275)
6.875
(174.625)
7.750
(196.85)
4.0
(101.6)
1.00
(25.4)
4-in. 6.875
(174.63)
7.125
(180.98)
7.625
(193.7)
8.125
(206.375)
8.250
(209.55)
9.250
(234.95)
4.0
(101.6)
1.00
(25.4)
6-in. 8.750
(222.25)
9.875
(250.83)
10.500
(266.7)
11.375
(288.925)
11.125
(282.575)
12.500
(317.5)
4.0
(101.6)
1.00
(25.4)
8-in. 11.000
(279.4)
12.125
(307.98)
12.625
(320.675)
14.125
(358.775)
13.875
(352.425)
15.250
(387.35)
6.0
(127)
1.5
(38.1)
10-in. 13.375
(339.73)
14.250
(361.95)
15.750
(400.05)
17.125
(434.975)
17.125
(434.975)
18.750
(476.25)
6.0
(152.4)
1.5
(38.1)
12-in. 16.125
(409.58)
16.625
(422.26)
18.000
(457.2)
19.625
(498.475)
20.500
(520.7)
21.625
(549.275)
6.0
(152.4)
1.5
(38.1)
14-in. 17.750
(450.85)
19.125
(485.78)
19.375
(339.725)
20.500
(520.7)
22.750
(577.85)
— 6.0
(152.4)
1.5
(38.1)
16-in. 20.250
(514.35)
21.250
(539.75)
22.250
(565.15)
22.625
(574.675)
25.250
(641.35)
— 6.0
(152.4)
1.5
(38.1)
18-in. 21.500
(546.1)
23.375
(593.725)
24.000
(609.6)
25.000
(635.00)
27.625
(701.675)
— 6.0
(152.4)
1.5
(38.1)
20-in. 23.750
(603.25)
25.625
(650.875)
26.750
(679.45)
27.375
(695.325)
29.625
(752.475)
— 6.0
(152.4)
1.5
(38.1)
24-in. 28.125
(714.375)
30.375
(771.525)
31.000
(787.4)
32.875
(835.025)
35.500
(901.7)
— 6.0
(152.4)
1.5
(38.1)
(1) Measurement is in inches (millimeters)
1495UC Orifice Universal Type
(Universal, Square edged, Concentric Line Size Diameter for Universal Type
(1)
2-in. 2.437 (61.8998)
2
1
/2-in. 2.812 (71.4248)
3-in. 3.437 (87.2998)
4-in. 4.406 (111.912)
6-in. 6.437 (163.5)
8-in. 8.437 (214.3)
10-in. 10.687 (271.45)
12-in. 12.593 (319.862)
14-in. 14.000 (355.6)
16-in. 16.000 (406.4)
18-in. 18.000 (457.2)
20-in. 20.000 (508)
24-in. 24.000 (609.6)
(1) Measurement is in inches (millimeters)
Diameter Handle
Length
Handle
Width
Diameter Handle
Length
Handle
Width
Diameter
