Reference Manual
00809-0100-4792, Rev CA
August 2010
Rosemount 1495, 1496
A-12
Flange Union Material Type
Standard Standard
C Carbon Steel ★
S 316/316L Stainless Steel ★
T DIN 1.4571 (316Ti Stainless Steel) ★
L 304/304L Stainless Steel ★
Expanded
H Alloy C-276
M Alloy 400
Options (Include with selected model number)
Alternate Pipe Schedule / Wall Thickness
(3)
Standard Standard
FA
(4)
Schedule 5S ★
FB
(4)
Schedule 10 ★
FC
(4)
Schedule 10S ★
FD
(4)
Schedule 20 ★
FE
(4)
Schedule 30 ★
FF
(4)
Schedule 40 ★
FG
(4)
Schedule 40S ★
FH
(4)
Schedule Standard (STD) ★
FI
(4)
Schedule 60 ★
FJ
(4)
Schedule 80 ★
FK
(4)
Schedule 80S ★
FL
(4)
Schedule Extra Strong (XS) ★
FM
(4)
Schedule 100 ★
FN
(4)
Schedule 120 ★
FP
(4)
Schedule 140 ★
FQ
(4)
Schedule 160 ★
FR
(4)
Schedule Double Extra Strong (XXS) ★
High Temperature Gaskets
Standard Standard
G1
(5)
High Temperature Gaskets (spiral wound gaskets) ★
Alternate Bolting Material
Standard Standard
SS
(6)
316SS Studs/Nuts ★
Alternate Pressure Tap Type
Standard Standard
ST Socketweld Pressure Taps (not available with Flange Union Type code DN) ★
Special Cleaning
Expanded
P2 Cleaned for Special Processes
Special Inspection
Standard Standard
QC1 Visual and dimensional inspection with certificate ★
Table A-1. Rosemount 1496 Orifice Flange Union Ordering Table
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
