Rosemount 1495 - 1496 Weights (Estimated)

Reference Manual
00809-0100-4792, Rev CA
August 2010
4-12
Rosemount 1495, 1496
1496 WEIGHTS
(ESTIMATED)
Weights are in pounds (kilograms).
Estimated weight based on:
ANSI schedule standard pipe
Carbon Steel materials of construction
Flange tap design
Any deviation in configuration may affect estimated weights.
Flange Ratings Line Size
2 in. (50 mm) 2.5 in. (64 mm) 3 in. (80 mm) 4 in. (100 mm) 6 in. (150 mm) 8 in. (200 mm) 10 in. (250 mm)
ANSI 150 12 (5.44) 16 (7.27) 20 (9.09) 30 (13.64) 48 (21.82) 78 (35.45) 104 (47.27)
300 18 (8.18) 24 (10.91) 30 (13.64) 50 (22.73) 84 (38.18) 134 (60.91) 182 (82.73)
600 24 (10.91) 36 (16.36) 46 (20.91) 84 (38.18) 162 (73.64) 240 (109.09) 380 (172.73)
900 50 (22.73) 72 (32.73) 82 (37.27) 102 (46.36) 220 (100.00) 350 (159.09) 520 (236.36)
1500 50 (22.73) 72 (32.73) 96 (43.64) 146 (66.36) 330 (150.00) 550 (250.00) 910 (413.64)
2500 84 (38.18) 104 (47.27) 188 (85.45) 290 (131.82) 760 (345.45) 1160 (527.27) 2150 (977.27)
RTJ 300 19 (8.64) 25 (11.36) 31 (14.09) 51 (23.18) 85 (38.63) 136 (61.82) 184 (83.64)
600 25 (11.36) 37 (16.82) 47 (21.36) 85 (38.64) 163 (74.09) 242 (110.00) 382 (173.64)
900 51 (23.18) 73 (33.18) 83 (37.73) 103 (46.82) 221 (100.45) 352 (160.00) 522 (237.27)
1500 51 (23.18) 73 (33.18) 97 (44.09) 147 (66.82) 331 (150.45) 552 (250.91) 912 (414.54)
2500 85 (38.64) 105 (47.73) 189 (85.91) 291 (132.27) 761 (345.91) 1162 (528.18) 2152 (978.18)
Flange Ratings Line Size
12 in. (300 mm) 14 in. (350 mm) 16 in. (400 mm) 18 in. (450 mm) 20 in. (500 mm) 22 in. (550 mm) 24 in. (600 mm)
ANSI 150 160 (72.72) 220 (99.79) 280 (127.00) 300 (136.08) 360 (163.29) 450 (204.12) 520 (235.87)
300 280 (127.27) 360 (163.29) 500 (226.79) 640 (290.30) 800 (362.87) 930 (421.84) 1160 (526.17)
600 450 (204.54) 560 (254.01) 780 (353.80) 950 (430.91) 1180 (535.23) 1440 (653.17) 1660 (752.96)
900 650 (295.45) 800 (362.87) 990 (449.05) 1360 (616.88) 1660 (752.96) 2500 (1133.98) 3000 (1360.77)
1500 1380 (627.27) 1880 (852.75) 2500 (1133.98) 3250 (1474.17) 4100 (1859.72) 5200 (2358.68) 6650 (3016.38)
2500 3050 (1386.36) 4050 (1837.04) 5100 (2313.32) 6450 (2925.67) 7200 (3265.86) 8250 (3742.13) 9300 (4218.40)
RTJ 300 282 (128.18) 362 (164.20) 503 (228.16) 643 (291.66) 803 (364.23) 933 (423.20) 1164 (527.98)
600 452 (205.45) 562 (254.92) 783 (355.16) 953 (432.27) 1183 (536.60) 1443 (654.53) 1664 (754.78)
900 652 (296.36) 802 (363.78) 993 (450.42) 1363 (618.24) 1663 (754.32) 2500 (1133.98) 3004 (1362.59)
1500 1382 (628.18) 1882 (853.66) 2503 (1135.34) 3253 (1475.53) 4103 (1861.09) 5100 (2313.32) 6654 (3018.20)
2500 3052 (1387.27) 4100 (1859.73) 5150 (2335.99) 6200 (2812.27) 7300 (3311.22) 8400 (3810.17) 9400 (4263.76)
