Rosemount 1495, 1496
ROSEMOUNT 1495
CONFIGURATION
Standard configuration is with a square-edged concentric bore in both paddle
and universal type plates. Also available with a spiral finish. Final inspection
reports illustrating plate thickness, concentricity, outside dimensions, inside
dimensions, roundness, and flatness are available.
• Bore calculations are available if the Configuration Data Sheet (CDS) is
completed and Option BC is selected.
• Line sizes larger than 24-in.
(609.6 mm) are available. Contact
Emerson Process Management.
Ordering Information
Table A-3. Rosemount 1495 Orifice Plate Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Model Product Description
1495 Orifice Plate Primary
Orifice Plate Type
Standard Standard
PC Paddle, Concentric ★
PG Paddle, Concentric, Spiral finish ★
UC Universal, Concentric ★
Line Size
Standard Standard
020 2 inches (DN50) ★
025 2 1/2 inches (DN65) ★
030 3 inches (DN80) ★
040 4 inches (DN100) ★
060 6 inches (DN150) ★
080 8 inches (DN200) ★
100 10 inches (DN250) ★
120 12 inches (DN300) ★
140 14 inches (DN350) ★
160 16 inches (DN400) ★
180 18 inches (DN450) ★
200 20 inches (DN500) ★
240 24 inches (DN600) ★
Flange Rating
Standard Standard
A1 Flange ANSI Class 150 Raised Face ★
A3 ANSI Class 300 Raised Face ★
A6 ANSI Class 600 Raised Face ★
A9 ANSI Class 900 Raised Face ★
AF ANSI Class 1500 Raised Face ★
AT
(1)
ANSI Class 2500 Raised Face ★
D1 DIN PN10 ★
D2 DIN PN16 ★
D3 DIN PN25 ★
D4 DIN PN40 ★
D5 DIN PN63
(2)
★
D6 DIN PN100 ★
