Rosemount 1495 - Ordering Information

Reference Manual
00809-0100-4792, Rev CA
August 2010
A-11
Rosemount 1495, 1496
Ordering Information
Table A-1. Rosemount 1496 Orifice Flange Union Ordering Table
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Model Product Description
1496 Orifice Flange Union
Flange Union Type
Standard
Standard
WN Raised Face, Weld Neck
★
TH Raised Face, Threaded
★
SO Raised Face, Slip-On
★
DN Raised Face, Weld Neck, DIN 19214 Part 1
★
Expanded
RJ Ring Joint, Weld Neck
Line Size
Standard Standard
020 2 inches (DN50) ★
025 2½-inches (DN65) ★
030 3 inches (DN80) ★
040 4 inches (DN100) ★
060 6 inches (DN150) ★
080 8 inches (DN200) ★
100 10 inches (DN250) ★
120 12 inches (DN300) ★
140 14 inches (DN350) ★
160 16 inches (DN400) ★
180 18 inches (DN450) ★
200 20 inches (DN500) ★
240 24 inches (DN600) ★
Flange Rating
Standard Standard
A3 ANSI Class 300 ★
A6 ANSI Class 600 ★
A9 ANSI Class 900 ★
AF ANSI Class 1500 ★
AT
(1)
ANSI Class 2500 ★
D1 DIN PN10
★
D2 DIN PN16
★
D3 DIN PN25
★
D4 DIN PN40
★
D5 DIN PN63
(2)
★
D6 DIN PN100
★
Expanded
R3 Ring-Type Joint (RTJ) Class 300
R6 Ring-Type Joint (RTJ) Class 600
R9 Ring-Type Joint (RTJ) Class 900
RF Ring-Type Joint (RTJ) Class 1500
RT Ring-Type Joint (RTJ) Class 2500
