Figure B-4. Examples of Installations With a 19-Tube Bundle Flow Straightener Downstream of a Single Bend
1 Position of any fitting placed at any distance upstream of the single bend.
2 Position of previous fitting placed before straight length upstream of the single bend.
3D
2D
13D
±
0.25D
30D
3D
2D
13D
12D
30D
18D
15D
1
2
